Plan 72904DA

Craftsman Ranch with Rocking Chair Porch

Heated S.F.
1,935
Beds
3
Baths
2.5
Stories
2
Cars
2

Floor Plan

Plan 72904DA

Main Level
Main Level
2nd Floor
2nd Floor

Plan 72904DA

M-F 9am-5pm EST |

1-203-761-8500

Main Level

Plan 72904DA: Craftsman Ranch with Rocking Chair Porch - Floor Plan - Main Level - Craftsman, Northwest, Ranch

2nd Floor

Plan 72904DA: Craftsman Ranch with Rocking Chair Porch - Floor Plan - 2nd Floor - Craftsman, Northwest, Ranch

Plan Details

  • The covered porch on this 3-bed Craftsman ranch home plan is the perfect place for a swinging bench or a couple of comfortable chairs.
  • The entry opens up into the vaulted living room through a cased opening on the right.
  • A cozy fireplace continues to draw you in and the room opens up to the vaulted dining room and kitchen.
  • To the let of the entry a hallway takes you pass the stairs leading to the additional bedrooms and bonus room upstairs and towards the owners' suite.
  • Owners' suite features include a walk-in closet, dual vanity that is separated from the shower and toilet.

What's Included

Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
  • Cover Sheet/Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
  • Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
  • Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
  • Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
  • Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details. Foundation types vary; please call to confirm the foundation type of the plan you are interested in.
  • Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc. Specific details such as fireplaces, stairways, decks, etc. Details are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
  • Building Section: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation.
  • Electrical Plan: A schematic layout of all lighting, switches, and electrical outlets.

What's Not Included

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Ready to Get Started?

Select your plan set options before checkout.

Price Match Guarantee
What's included?

Modify this Plan

Receive a free modification quote within 3 business days.

Start with a Cost Report

Calculate the cost to build & furnish your home.

Square Footage Breakdown

Total Heated Area

1,935 sq. ft.

1st Floor

1,375 sq. ft.

2nd Floor

560 sq. ft.

Bonus

342 sq. ft.

Covered Patio

144 sq. ft.

Beds/Baths

Bedrooms

3

Full bathrooms

2

Half bathrooms

1

Foundation Type

Standard Foundations

Crawl

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

82' 0"

Depth

40' 0"

Max Ridge Height

26' 0"

Garage

Type

Attached

Area

576 sq. ft.

Count

2 Cars

Entry Location

Side

Roof Details

Primary Pitch

8 on 12

Architectural Style

Craftsman

Northwest

Ranch

Special Features

Master Suite - 1st Floor

Optionally Finished Bonus Room

Square Footage Breakdown

Total Heated Area

1,935 sq. ft.

1st Floor

1,375 sq. ft.

2nd Floor

560 sq. ft.

Bonus

342 sq. ft.

Covered Patio

144 sq. ft.

Beds/Baths

Bedrooms

3

Full bathrooms

2

Half bathrooms

1

Foundation Type

Standard Foundations

Crawl

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

82' 0"

Depth

40' 0"

Max Ridge Height

26' 0"

Garage

Type

Attached

Area

576 sq. ft.

Count

2 Cars

Entry Location

Side

Roof Details

Primary Pitch

8 on 12

Architectural Style

Craftsman

Northwest

Ranch

Special Features

Master Suite - 1st Floor

Optionally Finished Bonus Room
