Plan 22507DR Detached Garage Plan with Storage and Man Door

Detached Garage Plan with Storage and Man Door

Plan 22507DR

  • 0

    Heated s.f.

  • 0

    Beds

  • 1

    Stories

  • 1

    Cars

  • This detached garage plan has a board and batten exterior with stone detailing.
  • There is parking for one car inside.
  • The man door opens to give you access to storage.

Each plan includes the following:

* 4 Elevations
* Foundation Plan
* Main Floor Plan
* Upper Floor Plans (if applicable)
* Roof Plan
* Building Section
* Construction Details
* Typical Wall Section

These items are NOT included:
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical and Electrical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required


Floor Plan

NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Detached Garage Plan with Storage and Man Door - 22507DR floor plan - Main Level

Plan details

Detached Garage Plan with Storage and Man Door

  • 0

    Heated s.f.

  • 0

    Beds

  • 0

    Baths

  • 1

    Floors

  • 1

    Car garage

Buy This Plan
  • PDF - Single-Build $350
  • CAD + PDF - Single-Build $650
  • View all purchase option online

About This Plan

  • This detached garage plan has a board and batten exterior with stone detailing.
  • There is parking for one car inside.
  • The man door opens to give you access to storage.

Floor Plans

  • Main Level

Plan Details

Square Footage Breakdown

  • Total Heated Area: 0 sq. ft.

Beds/Baths

  • Bedrooms: 0

Foundation Type

    • Standard Foundations: Slab

Exterior Walls

  • Standard Type(s): 2x6

Dimensions

  • Width: 20' 0"
  • Depth: 24' 0"
  • Max ridge height: 16' 0"

Garage

  • Type: Detached
  • Area: 448 sq. ft.
  • Count: 1 Cars
  • Entry Location: Front

Ceiling Heights

  • Floor / Height: First Floor / 10' 0"

Roof

  • Primary Pitch: 6 on 12
  • Framing Type: Truss
