Detached Garage with Buildable Space Above

Plan 21199DR

0
Heated s.f.
0
Beds
1-2
Stories
1
Cars

This garage plan has 576 s.f. on the main level and 277 s.f. above for storage.
Matching House Plan: This garage plan matches house plan 21282DR and 21553DR.

Each plan includes the following:

* 4 Elevations

* Foundation Plan

* Main Floor Plan

* Upper Floor Plans (if applicable)

* Roof Plan

* Truss Diagrams & Building Section

* Construction Details

* Typical Wall Section

These items are NOT included:

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical and Electrical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required

Floor Plan

Main Level

Reverse Floor Plan

NOTE:

If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.

Detached Garage with Buildable Space Above - 21199DR floor plan - Main Level

2nd Floor

Reverse Floor Plan

NOTE:

If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.

Detached Garage with Buildable Space Above - 21199DR floor plan - 2nd Floor

Plan details

Square Footage Breakdown

Total Heated Area: 0 sq. ft.

Bonus: 277 sq. ft.

Beds/Baths

Bedrooms: 0

Foundation Type

Standard Foundations: Slab

Exterior Walls

Standard Type(s): 2x4

Dimensions

Width: 24' 0"
Depth: 24' 0"
Max ridge height: 22' 2"

Garage

Type: Detached
Area: 576 sq. ft.
Count: 1 Cars
Entry Location: Front

Roof Details

Framing Type: Stick

Special features
