Plan 59335ND
Duplex with 3 Bed Units Under 1500 Square Feet
Heated S.F.
2,974
Units
2
Width
Depth
Floor Plan

Plan 59335ND

Main Level
slide image 0

Plan 59335ND

1-800-854-7852

1-262-521-4596

Main Level
floor plan image Main Level
Plan Details
  • Each 3 bed, 2 bath unit gives its owners 1,487 square feet of heated living  and a 561 square foot 2-car garage.
  • Feel the flair as you step onto the covered entry porch of this duplex home plan complete with traditional columns and fluid entry into a formal foyer.
  • Enjoy cozy nights at home in your spacious great room or entertain friends on warm summer evenings on your covered back porch.
  • Early morning breakfasts are a delight with an eat-at kitchen bar opening to a quiet breakfast nook.
Unit A
1,487Sq. Ft.
1487 Sq. Ft.
1st Floor
3Beds
2Full Baths
2Vehicle
Attached
561 Sq. Ft.
39'width
73' 10"depth
27'height
Unit B
1,487Sq. Ft.
1487 Sq. Ft.
1st Floor
3Beds
2Full Baths
2Vehicle
Attached
561 Sq. Ft.
39'width
73' 10"depth
27'height
What's Included
  • Foundation Plan (1/4″ or 1/2″ = 1′)
  • Floor Plans (1/4″= 1′)
  • Set of Elevations (1/4″= 1′)
  • Miscellaneous Details (3/4″ = 1′)
  • An electrical diagram showing a bird's-eye view of rooms with lights, fans to switches
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Modify This Plan
Need to make changes? We will get you a free price quote within 1 to 3 business days.
Contact Us

Square Footage Breakdown

Total Heated Area

2,974 sq. ft.

1st Floor

2,974 sq. ft.

Porch, Front

73 sq. ft.

Porch, Rear

144 sq. ft.

Beds/Baths

Bedrooms

4, 5, or 6

Full bathrooms

4

Foundation Type

Standard Foundations

Crawl, Slab

Exterior Walls

Exterior Walls

2x4

Optional Type(s)

2x6

Dimensions

Width

78' 0"

Depth

73' 10"

Max Ridge Height

27' 0"

Garage

Type

Attached

Area

1122 sq. ft.

Count

4 Cars

Entry Location

Front

Ceiling Heights

First Floor

9'

Roof Details

Primary Pitch

12 on 12

Framing Type

Stick

Special Features

Bedrooms - Clustered

Breakfast Nook

Master Suite - 1st Floor

Master Suite - 2nd Floor

Square Footage Breakdown

Total Heated Area

2,974 sq. ft.

1st Floor

2,974 sq. ft.

Porch, Front

73 sq. ft.

Porch, Rear

144 sq. ft.

Beds/Baths

Bedrooms

4, 5, or 6

Full bathrooms

4

Foundation Type

Standard Foundations

Crawl, Slab

Exterior Walls

Exterior Walls

2x4

Optional Type(s)

2x6

Dimensions

Width

78' 0"

Depth

73' 10"

Max Ridge Height

27' 0"

Garage

Type

Attached

Area

1122 sq. ft.

Count

4 Cars

Entry Location

Front

Ceiling Heights

First Floor

9'

Roof Details

Primary Pitch

12 on 12

Framing Type

Stick

Special Features

Bedrooms - Clustered

Breakfast Nook

Master Suite - 1st Floor

Master Suite - 2nd Floor
