Eureopean-style House Plan with Striking Courtyard and a Second Floor Guest Suite
Heated S.F.
2,909
Beds
4
Baths
3.5
Stories
2
Cars
2
What's Included
Plan Details
  • This striking European-style courtyard home plan has 2,909 square feet of living area. It features four spacious bedrooms and three full and one half bathrooms.
  • French doors and an open floor plan blend indoor and outdoor living. Inside, arches and columns provide definition to the kitchen, dining and great rooms. French doors extend the living areas to the covered porch. The gourmet kitchen incorporates a step-saving design and services the great room through a pass-thru. A large central island serves as a prep area as well as a place for quick meals.
  • The great room with a cozy fireplace and a wall of built-ins is a great gathering place for family and friends. The study is secluded away from the public realm for some quiet reading/studying time.
  • The second level is reserved for the private bedrooms and bathrooms. The master retreat French doors extend out to a covered balcony and porch The master retreat features large walk-in closets and a self-contained master bath. This level boasts its own wraparound covered porch accessible from two bedrooms (including the master) and the hall.
  • The bonus room/guest suite performs as a self-sufficient studio apartment or distinctly separate home office. The separate entrance grants it independence from the house proper.
What's Included
  • Cover Sheet, Index
  • Wall Sections & Notes
  • Typical Detail & Notes
  • Foundation Plan
  • Floor Plans
  • Reflected Ceiling Plan showing ceiling heights and treatments
  • Floor Framing Plan (basement, crawlspace or 2-story homes only)
  • Birds Eye Roof Plan
  • All Elevations
  • Building Section & Details
  • Interior Elevations (Details may vary based on the design)
  • Suggested Electrical Layout
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
