Exclusive 3-Bed House Plan with Split Bedroom Layout
Heated S.F.
2,000
Beds
3
Baths
2
Stories
1
Cars
2
What's Included
Plan Details
  • Matching sets of columns support the covered entry on this 3-bed house plan with a split bedroom layout.
  • Step inside and you have views that extend through the great room with fireplace to the back of the home.
  • The kitchen has an angled peninsula that gives you casual seating on one side and a double sink and work space on the other.
  • The breakfast room has sliding doors that open to the outdoors and the dining room has a try ceiling.
  • A split bedroom layout maximizes your privacy. The master suite has easy access to the laundry through a pocket door. Across the home, two bedrooms share a bath.
What's Included
  • Cover sheet with notes
  • Elevations
  • Basement and foundation plan and typical wall section
  • Detailed floor plans
  • Sections
  • Roof plan
  • Details
  • Reinforcing notes
What's Not Included
  • Electrical Plans
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

Exclusive 3-Bed House Plan with Split Bedroom Layout

  • 2,000

    Heated s.f.

  • 3

    Beds

  • 2

    Baths

  • 1

    Floors

  • 2

    Car garage

Floor Plan

  • Main Level

Plan Details

Square Footage Breakdown

  • Total: 2,000 sq. ft.
  • 1st Floor: 2,000 sq. ft.

Dimensions

  • Width: 58' 8"
  • Depth: 62' 0"
  • Max ridge height: 26' 6"

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2

Garage

  • Type: Attached
  • Area: 572 sq. ft.
  • Count: 2 Cars
  • Entry Location: Front

Foundation Type

    • Standard Foundations: Basement

Exterior Walls

  • Standard Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 9' 0"

Roof

  • Primary Pitch: 10 on 12
  • Framing Type: Stick And Truss
