Exclusive Modern Colonial House Plan with Finished Basement

Plan 93170EL

  • 5,157

    Heated s.f.

  • 5

    Beds

  • 5.5

    Baths

  • 2

    Stories

  • 4

    Cars

  • Eyebrow dormers and cupolas provide eye-catching elements on the exterior of this exclusive Modern Colonial house plan.
  • A double garage on either side of the design totals 4 bays and creates a motor courtyard for friends and family. Inside, the spacious family room, complete with a coffered ceiling, opens onto a terrace.
  • The scullery doubles the kitchen's workspace and includes a secondary sink, and the adjoining dining / keeping room extends onto a veranda.
  • Just off the foyer, a rotunda leads to the owner's suite with a deluxe bathroom, while the remaining bedrooms are located upstairs, each uniquely shaped with walk-in closets.
  • Finish the walkout basement and enjoy a game / card room with wet bar, home theater, and fitness room.
  • DELIVERY NOTE: Please allow 5 to 7 business days for delivery.

Each plan set includes the following:

  • Cover Sheet
  • General Note Sheet
  • Foundation Sheet
  • First Floor Plan
  • Second Floor Plan (if applicable)
  • Roof Framing Plan
  • Front & Rear Elevation
  • Left & Right Elevation
  • Openings & Sections Sheet
  • Foundation Details
  • Cornice Details
  • First Floor Electrical
  • Second Floor Electrical (if applicable)
These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Exclusive Modern Colonial House Plan with Finished Basement - 93170EL floor plan - Main Level
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Exclusive Modern Colonial House Plan with Finished Basement - 93170EL floor plan - 2nd Floor
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Exclusive Modern Colonial House Plan with Finished Basement - 93170EL floor plan - Basement

Exclusive Modern Colonial House Plan with Finished Basement

  • 5,157

    Heated s.f.

  • 5

    Beds

  • 5.5

    Baths

  • 2

    Floors

  • 4

    Car garage

Floor Plan

  • Main Level

  • 2nd Floor

  • Basement

Plan Details

Square Footage Breakdown

  • Total: 5,157 sq. ft.
  • 1st Floor: 3,219 sq. ft.
  • 2nd Floor: 1,938 sq. ft.

Dimensions

  • Width: 123' 9"
  • Depth: 99' 5"
  • Max ridge height: 40' 2"

Beds/Baths

  • Bedrooms: 5
  • Full bathrooms: 5
  • Half bathrooms: 1

Garage

  • Type: Attached
  • Area: 1384 sq. ft.
  • Count: 4 Cars
  • Entry Location: Courtyard

Foundation Type

    • Standard Foundations: Crawl
    • Optional Foundations: Walkout, Slab, Basement

Exterior Walls

  • Standard Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 10' 0" Second Floor / 9' 0"
