Great Family-Sized Home Plan

Plan 3923ST

  • 1,770

    Heated s.f.

  • 3

    Beds

  • 2.5

    Baths

  • 2

    Stories

  • 2

    Cars

  • A brick facade decorated with assorted window designs creates a beautiful exterior to this charming home plan.
  • Large rooms, a warm fireplace, split stairs and a kitchen with breakfast bar and an abundance of counter space highlight the first floor.
  • Access to the laundry room and garage are neatly organized in a secluded hall.
  • A second floor master bedroom with raised ceiling will be remembered for its elegant master bath with whirlpool tub, double bowl vanity, separate shower stall, and large walk-in closet. Two additional bedrooms make this a great family sized home.
  • Ceilings: 8'.
  • Foundation: basement, daylight basement. Please specify when ordering.
  • Related Plan: Get a 4th bedroom with house plan 39041ST.

  • General notes and specifications
  • Front, rear and side elevations at (1/4" scale)
  • Foundation plan (1/4" scale) indicating beam and column sizes along with lower level framing
  • Reinforced foundation and footing details
  • First floor plan (1/4" scale) includes all necessary framing information, window rough openings, beam sizes and framing details for specialized areas
  • Stairs, sections, cabinet layouts, window flashing and miscellaneous details necessary for understanding of construction methods
  • Roof plan (1/8" scale) indicating pitches and wall height as well as truss profiles indicating heel heights and raised ceiling areas
  • Wall section indicating standard materials and detailing for typical wall construction
