Handsome Acadian House Plan

Name: Plan 56395SM: Handsome Acadian House Plan
Brand: Architectural Designs
SKU: 56395SM
Price: 1245.0 USD
Availability: InStock

Heated S.F.

1,873

Beds

Baths

Stories

Cars

Floor Plan

This Acadian house plan proudly displays its Southern roots with its hip roof and big front porch supported by four graceful columns.
A key design element is the big open floor plan that is visible as soon as you enter the home.
All the main rooms in the house share one open space so you can see the living room fireplace from the kitchen and dining room as well as from the foyer.
The bedroom wing is on the right side of the home with the master suite tucked in the rear away from street noise.
The rear covered porch lets you enjoy the outdoors even on a rainy day and protects you from the sun.
NOTE: Please allow a 5 to 10 day delay for 2x6 option to be completed.

FLOOR PLAN: Showing all dimensions, window & door locations, laminated beams, columns, floor materials, ceiling heights, fireplace size, window & door schedules and specifications
DOOR, WINDOW AND ROOF FINISH SCHEDULES: Window & Door schedules as well as room finish schedules showing flooring specs, crown molding, cabinets, countertop materials, & ceiling heights.
FOUNDATION PLAN AND CEILING JOISTS LAYOUT: Dimensioned plan detailing the location and size of footings, slabs, brick shelves reinforcing steel, direction and size of ceiling joists, Laminate beam locations, specifications covering soil pressure, concrete strength, and requirements for the contractor to follow accepted practices.
ELECTRICAL PLAN: Specifications, notes, schedules, and plan defining the location of panels, service, lighting fixtures, switches, outlets, smoke detectors, cable TV and telephones.
FRONT AND REAR ELEVATIONS: The front and rear elevation of the house as drawn. Shows placement of doors & windows on exterior of house, as well as roof pitches, and locations of chimney, exterior vents, etc. and also includes any necessary details.
SIDE ELEVATIONS, ROOF PLANS, WALL SECTIONS AND FRAMING DETAILS: Side views of house, and necessary framing and roofing details. Also included are wall sections, and any other necessary details for your framer or other subcontractors.

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required
