Hip Roof Drive-Thru Garage

Plan 22055SL

  • 0

    Heated s.f.

  • 0

    Beds

  • 1

    Stories

  • 2

    Cars

  • A classic brick and siding facade enhances the exterior of this detached two-car garage.
  • Covering a wide range of uses, this drive-thru garage design provides two 9'x7' overhead doors in front and one 9'x7' overhead door in back.
  • A convenient man-door and a 9' ceiling complete this stylish garage plan.
  • Related Plan: For a siding version, see garage plan 22052SL.
  • Get a double-wide door with 22054SL (siding) and 22056SL (brick).
  • Get a three car garage with garage plan 22053SL

Each plan set includes the following:

  • Foundation plan
  • Fully dimensioned floor plans
  • Exterior elevations
  • Roof plan
  • Electrical plan
  • Cabinet elevations
  • Building section
  • Typical stair and wall sections and other related details

Floor Plan

Plan details

Special features



Hip Roof Drive-Thru Garage

  • 0

    Heated s.f.

  • 0

    Beds

  • 0

    Baths

  • 1

    Floors

  • 2

    Car garage

Buy This Plan
  • 5 Sets $260
  • PDF - single-use $300
  • 8 Sets $325
  • CAD $425
  • PDF - multi-use $800
  • CAD - multi-use $925
  • View all purchase option online

About This Plan

  • A classic brick and siding facade enhances the exterior of this detached two-car garage.
  • Covering a wide range of uses, this drive-thru garage design provides two 9'x7' overhead doors in front and one 9'x7' overhead door in back.
  • A convenient man-door and a 9' ceiling complete this stylish garage plan.
  • Related Plan: For a siding version, see garage plan 22052SL.
  • Get a double-wide door with 22054SL (siding) and 22056SL (brick).
  • Get a three car garage with garage plan 22053SL

Floor Plans

  • Main Level

Plan Details

Square Footage Breakdown

  • Total Heated Area: 0 sq. ft.

Beds/Baths

  • Bedrooms: 0

Foundation Type

    • Standard Foundations: Slab

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Dimensions

  • Width: 30' 0"
  • Depth: 26' 4"
  • Max ridge height: 17' 0"

Garage

  • Type: Detached
  • Area: 780 sq. ft.
  • Count: 2 Cars
  • Entry Location: Front

Ceiling Heights

  • Floor / Height: First Floor / 9' 0"

Roof

  • Primary Pitch: 6 on 12
  • Secondary Pitch: 7 on 12
  • Framing Type: Truss
