Incredible Mountain Home Plan

Plan 11565KN

  • 5,414

    Heated s.f.

  • 3

    Beds

  • 3.5

    Baths

  • 2

    Stories

  • 2

    Cars

  • Windows soak up the views all across the back of this fabulous Mountain home.
  • Step out onto the huge wrap-around deck and enjoy the fresh air.
  • Log siding enhances the home, with its decorative log trim.
  • Inside, the floor plan is wide open to encourage sweeping views from room to room.
  • There are two confortable bedrooms on the main level.
  • Upstairs belongs mostly to the vaulted master bedroom suite with its own private covered deck.
  • A huge vaulted sitting area is shared with a second bedroom suite that has a mini-kitchen making it perfect as an in-law suite.
  • Work out in your own exercise room on the lower level, complete with sauna and bathroom.
  • The enormous rec room on this level has a fireplace and plenty of room for a big pool table.

Floor plans at ¼" scale

All exterior elevations at ¼" scale

Roof plan at ¼" scale

Building sections at ¼" scale

Completed foundation plan at ¼" scale

Completed floor/roof framing plan at ¼" scale

Building height profiles at ¼" scale

Door and window schedules

General construction notes and building schedules

Exterior finish schedule

Architectural details

Construction details for cabinets, interior built-ins and stairs

Designations for all floor, wall and ceiling surfaces

Details and specifications for all ceiling treatments

All square footage calculations

These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Incredible Mountain Home Plan - 11565KN floor plan - Basement
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Incredible Mountain Home Plan - 11565KN floor plan - Main Level
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Incredible Mountain Home Plan - 11565KN floor plan - 2nd Floor

Incredible Mountain Home Plan

  • 5,414

    Heated s.f.

  • 3

    Beds

  • 3.5

    Baths

  • 2

    Floors

  • 2

    Car garage

Floor Plan

  • Basement

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total: 5,414 sq. ft.
  • Lower Level: 1,470 sq. ft.
  • 1st Floor: 2,268 sq. ft.
  • 2nd Floor: 1,676 sq. ft.

Dimensions

  • Width: 74' 0"
  • Depth: 80' 0"
  • Max ridge height: 36' 0"

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 3
  • Half bathrooms: 1

Garage

  • Type: Attached
  • Area: 678 sq. ft.
  • Count: 2 Cars
  • Entry Location: Front

Foundation Type

    • Standard Foundations: Basement, Walkout

Exterior Walls

  • Standard Type(s): 2x6

Ceiling Heights

  • Floor / Height: Lower Level / 10' 0" First Floor / 10' 0" Second Floor / 9' 0"
