Plan 510037WDY

Large Southern House Plan

Heated S.F.
3,723
Beds
4
Baths
3.5
Stories
2
Cars
3

Floor Plan

Plan 510037WDY

Main Level
Main Level
2nd Floor
2nd Floor

Plan 510037WDY

M-F 9am-5pm EST |

1-203-761-8500

Main Level

Plan 510037WDY: Large Southern House Plan - Floor Plan - Main Level - Acadian, European, French Country, Louisiana-Style, Southern

2nd Floor

Plan 510037WDY: Large Southern House Plan - Floor Plan - 2nd Floor - Acadian, European, French Country, Louisiana-Style, Southern

Plan Details

  • A graceful, arched front door gives this Southern house plan a European look.
  • The big two-way fireplace separates the living room from the keeping room, with an easy flow between the rooms.
  • Ward off those chilly nights as you gather around the outdoor fireplace on the back porch.
  • Homeowners get a gorgeous first floor master suite with an elegant tray ceiling, giant master bathroom and an L-shaped walk-in closet.
  • A media room on the second floor has a hallway to a small second floor porch where you can grab some fresh air.
  • The connected bathroom separates bedrooms 3 and 4, each with a walk-in closet.
  • Add bonus space to gain an extra 326 square feet of living space.

What's Included

This plan has 9 pages as follows:
  1. Coversheet Color Rendering
  2. First Floor Plan with Dimensions, Notes, Door and Window Sizes, Beam Sizing
  3. Second Floor Plan with Dimensions, Notes, Door and Window Sizes, Beam Sizing
  4. All Four Exterior Elevation, Roof Plan, Flashing Detail
  5. Building Section, Cornice Detail, Stair Detail, Roof Support Detail, Jack Arch Detail, Flashing Detail, Rafter Span Schedule
  6. First Floor Electrical Plan and Schedules
  7. Second Floor Electrical Plan and Schedules
  8. Slab Foundation
  9. Footing Details

What's Not Included

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Ready to Get Started?

Select your plan set options before checkout.

Price Match Guarantee
What's included?

Modify this Plan

Receive a free modification quote within 3 business days.

Start with a Cost Report

Calculate the cost to build & furnish your home.

Square Footage Breakdown

Total Heated Area

3,723 sq. ft.

1st Floor

2,553 sq. ft.

2nd Floor

1,170 sq. ft.

Bonus

326 sq. ft.

Porch, Rear

299 sq. ft.

Beds/Baths

Bedrooms

4

Full bathrooms

3

Half bathrooms

1

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

2x4

Optional Type(s)

2x6

Dimensions

Width

59' 11"

Depth

101' 10"

Max Ridge Height

35' 2"

Garage

Type

Attached

Area

817 sq. ft.

Count

3 Cars

Entry Location

Courtyard

Ceiling Heights

First Floor

10'

Second Floor

9'

Roof Details

Primary Pitch

12 on 12

Secondary Pitch

12 on 12

Framing Type

Stick

Architectural Style

Acadian

European

French Country

Louisiana-Style

Southern

Special Features

Formal Dining

Jack & Jill Bath

Keeping Room

Laundry - Main Level

Library/Study

Master Suite - 1st Floor

Media Room

Optionally Finished Bonus Room

Outdoor Fireplace

Two Story Great Room

Wet Bar

Plan Collections

Photo Gallery

Square Footage Breakdown

Total Heated Area

3,723 sq. ft.

1st Floor

2,553 sq. ft.

2nd Floor

1,170 sq. ft.

Bonus

326 sq. ft.

Porch, Rear

299 sq. ft.

Beds/Baths

Bedrooms

4

Full bathrooms

3

Half bathrooms

1

Foundation Type

Standard Foundations

Slab

Exterior Walls

Exterior Walls

2x4

Optional Type(s)

2x6

Dimensions

Width

59' 11"

Depth

101' 10"

Max Ridge Height

35' 2"

Garage

Type

Attached

Area

817 sq. ft.

Count

3 Cars

Entry Location

Courtyard

Ceiling Heights

First Floor

10'

Second Floor

9'

Roof Details

Primary Pitch

12 on 12

Secondary Pitch

12 on 12

Framing Type

Stick

Architectural Style

Acadian

European

French Country

Louisiana-Style

Southern

Special Features

Formal Dining

Jack & Jill Bath

Keeping Room

Laundry - Main Level

Library/Study

Master Suite - 1st Floor

Media Room

Optionally Finished Bonus Room

Outdoor Fireplace

Two Story Great Room

Wet Bar

Plan Collections

Photo Gallery
