Luxurious Coastal House Plan with Four Bedrooms and Four-Car Garage

Name: Plan 65822BS: Luxurious Coastal House Plan with Four Bedrooms and Four-Car Garage
Brand: Architectural Designs
SKU: 65822BS
Price: 4165.0 USD
Availability: InStock

Heated S.F.

4,165

Beds

Baths

4.5

Stories

Cars

Floor Plan

Plan Details

This sprawling 4,165 square foot coastal estate features four bedrooms, four full baths, one half bath, and a generous 1,203 square foot four-car courtyard garage.
The grand entry opens into a sophisticated layout that balances expansive communal living spaces with private retreats, highlighted by a dedicated library or study for quiet work or reflection.
The main living area serves as the heart of the home, offering an open-concept flow that transitions seamlessly into a bright breakfast nook and gourmet kitchen.
A private master suite occupies its own wing, providing a serene sanctuary, while three additional bedrooms are strategically placed to ensure privacy for family members and guests alike.
The massive 967 square foot lanai acts as an extension of the interior, featuring a built-in outdoor kitchen and fireplace that invites year-round alfresco dining and relaxation.
Designed for convenience, the home includes a dedicated main-level laundry room and thoughtful architectural details that emphasize a seamless connection to the outdoors.
