Luxurious European House Plan with 5 Beds and Vaulted Great Room

Name: Plan 54075LK: Luxurious European House Plan with 5 Beds and Vaulted Great Room
Brand: Architectural Designs
SKU: 54075LK
Price: 2750.0 USD
Availability: InStock

Heated S.F.

4,789

Beds

Baths

5.5

Stories

Cars

Floor Plan

Plan Details

Spanning 4,789 finished sq ft, this European House Plan features 5 bedrooms, 5.5 baths, and an attached 702 sq ft 2-car garage.
A welcoming entry leads into a thoughtfully designed layout, offering immediate access to a private study and a casual dining room.
The main living areas flow seamlessly, encompassing a gourmet kitchen with a walk-in pantry, a cozy breakfast nook, and generous spaces for daily living and entertaining.
Enjoy dedicated recreation in the spacious game/rec room, ideal for family fun or hosting gatherings.
Expansive combined porches totaling 1,140 sq ft, complete with an outdoor kitchen, create exceptional opportunities for al fresco dining and relaxation.

What's Included

FLOOR PLAN: Showing all dimensions, window & door locations, laminated beams, columns, floor materials, ceiling heights, fireplace size, window & door schedules and specifications
FOUNDATION PLAN: Dimensioned plan detailing the location and size of footings, slabs, brick shelves reinforcing steel, direction and size of ceiling joists, Laminate beam locations, specifications covering soil pressure, concrete strength, and requirements for the contractor to follow accepted practices.
ELECTRICAL PLAN: Specifications, notes, schedules, and plan defining the location of panels, service, lighting fixtures, switches and outlets.
ELEVATIONS: The front, rear and side elevations of the house as drawn. Shows placement of doors & windows on exterior of house, as well as roof pitches, and locations of chimney, exterior vents, etc. and also includes any necessary details.
ROOF PLANS: Provides a bird's eye view of the roof's valleys, ridges and dormers, if applicable
BUILDING CROSS SECTION: Shows details of the house as though it were cut in slices from the roof to the foundation. The cross sections detail the construction of the home, insulation, flooring and roofing.
INTERIOR ELEVATIONS: Show's how the details of cabinets such as those found in the kitchen, bathroom and utility room, fireplaces and other special interior features.
NOTES AND DETAILS: Provides information for structural specifications, excavating and grading, masonry and concrete work, carpentry and wood specifications, thermal and moisture protection and specifications about drywall, tile, flooring, glazing, caulking and sealants.

What's Not Included

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required
