Plan 17522LV
Luxury Craftsman with Great Photos
Heated S.F.
4,079
Beds
5
Baths
5.5
Stories
2
Cars
3
What's Included
Plan Details
  • This luxury craftsman home plan has a large master suite equipped with dual walk-in closets, a large bath and sitting room that has access to the covered porch on the rear.
  • The arched entries to the dining room and the gathering room along with the coffered ceiling accent the first floor perfectly.
  • A gracious gathering room with fireplace flanked by built-in bookcases opens onto a covered porch.
  • Three suites and a rec room complete the upstairs.
  • Related Plan: Need a basement? See house plan 17521LV (5,460 sq. ft.).
What's Included
  • Dimensioned and detailed Foundation plan (type as listed on home plan description)
  • Dimensioned and detailed floor plans
  • Framing plans
  • Complete front, side and rear elevations
  • Roof plan
  • Typical building sections (as deemed necessary for construction)
  • Typical foundation details, wall sections, and cornice details necessary for construction
  • Separate electrical plan (may be shown on floor plans in some cases)
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

Luxury Craftsman with Great Photos

  • 4,079

    Heated s.f.

  • 5

    Beds

  • 5.5

    Baths

  • 2

    Floors

  • 3

    Car garage

Floor Plan

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total: 4,079 sq. ft.
  • 1st Floor: 2,481 sq. ft.
  • 2nd Floor: 1,598 sq. ft.

Dimensions

  • Width: 73' 10"
  • Depth: 78' 4"

Beds/Baths

  • Bedrooms: 5
  • Full bathrooms: 5
  • Half bathrooms: 1

Garage

  • Type: Attached
  • Area: 772 sq. ft.
  • Count: 3 Cars
  • Entry Location: Side

Foundation Type

    • Standard Foundations: Crawl

Exterior Walls

  • Standard Type(s): 2x4

Ceiling Heights

  • Floor / Height: First Floor / 10' 0" Second Floor / 9' 0"
