Modern Barndominium Carriage House Plan with Four-Car Garage

Name: Plan 623682DJ: Modern Barndominium Carriage House Plan with Four-Car Garage
Brand: Architectural Designs
SKU: 623682DJ
Price: 1499.0 USD
Availability: InStock

Heated S.F.

1,988

Beds

Baths

2.5

Stories

Cars

Tour

Floor Plan

Plan Details

This 1,988 square foot modern barndominium carriage house plan offers three bedrooms, two-and-a-half baths, and a massive 1,771 square foot four-car garage.
The entry experience begins at the ground level, where a dedicated mudroom provides a transition point before ascending the stairs to the main living level.
The upper floor features a vaulted open-concept layout where the great room, dining area, and kitchen flow together, anchored by a fireplace and access to a massive covered deck.
The primary suite is positioned for privacy on one side of the home, while two additional bedrooms share a Jack and Jill bathroom on the opposite side.
The kitchen is designed for efficiency and style, complete with a functional walk-in pantry and a central island that overlooks the gathering spaces.
Outdoor living is a highlight of this design, featuring an expansive 15 by 52 foot covered deck that serves as an ideal elevated vantage point for mountain or meadow views.

What's Included

Cover Sheet: Shows the front elevation and typical notes and requirements.
Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurement
Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor
Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible.
Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
Roof Plan
Typical Wall Section
Typical Stair Section (if applicable)
Cabinets Elevations (if applicable)

View Sample Plan

What's Not Included

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required
