Plan 33282ZR

Modern Coastal Contemporary House Plan with 4 Bedrooms and 4 Car Garage

Name: Plan 33282ZR: Modern Coastal Contemporary House Plan with 4 Bedrooms and 4 Car Garage
Brand: Architectural Designs
SKU: 33282ZR
Price: 2950.0 USD
Availability: InStock

Heated S.F.

3,671

Beds

4 - 5

Baths

3.5+

Stories

Cars

Floor Plan

Plan Details

This 3,671 square foot coastal contemporary residence features 4 to 5 bedrooms, 3 full baths, 2 half baths, and a spacious 1,286 square foot four-car garage.
A striking symmetrical facade welcomes you with angled wings and a grand covered entry that opens into a foyer bathed in natural light from high transom windows.
The dramatic open-concept great room serves as the heart of the home, seamlessly connecting to a gourmet kitchen and dining area while utilizing pocketing sliders to blend indoor and outdoor living.
The primary suite occupies its own private wing, offering secluded luxury with direct lanai access, a massive walk-in closet, and a spa-inspired bathroom.
Three additional guest suites are located on the opposite side of the home, accompanied by a versatile study that opens directly to the rear outdoor space.
The expansive 1,383 square foot rear lanai is designed for ultimate relaxation, featuring a complete outdoor kitchen, a cozy fireplace, and direct access to a dedicated pool bath.
The dual garages provide generous space for four vehicles, including room for recreational equipment or a dedicated workshop area.

What's Included

COVER SHEET / INDEX / SITE PLAN - The Cover sheet contains an index of the sheets that will follow in the design development set of plans. It will also include a grayscale elevation or rendering depicting the look of the front of the home, and overall roof plan.
WALL SECTIONS - The Wall Section sheet depicts one or more sections of the home’s exterior walls from the foundation to the roof, calling out all materials and construction specifics.
FOUNDATION PLAN - The Foundation Plan sheet shows the home’s foundation layout depicting plumbing, footing, support walls, columns, etc., calling out the necessary notes, dimensions and details.
SECOND FLOOR FRAMING (where appropriate) - The Second Floor Framing sheet shows important locations of beams and load-bearing conditions, as well as the floor truss spacing and direction. The Second Floor Framing Plan is meant as general information for the truss manufacturer.
FLOOR PLANS - The Floor Plan sheet(s), show a detailed layout of the floor plans with dimensions, notes, call outs and keys relating to sheets with sections and details needed by your builder for construction. These plans will include window and door sizes and locations, and will also show the location of bathroom fixtures.
ROOF PLAN & SOFFIT (CHASE LAYOUT) PLAN - The Roof Plan sheet is a general layout of the home’s roof. It is meant as general information for the truss manufacturer and framing contractor. This sheet also contains the location and size of the dropped soffits housing the forced-air chases. (Ducts in Conditioned Space – DICS).
REFLECTED CEILING PLAN - The reflected ceiling plan shows all ceiling heights, treatments, and details including necessary notes.
EXTERIOR ELEVATIONS - The Exterior Elevation sheet(s) depict elevations for all sides of the home, showing dimensions and material notes and exterior detailing where needed.
CROSS SECTION & INTERIOR ELEVATIONS - The Cross Section sheet depicts a section through the home revealing floor, ceiling and roof heights at a strategic location. The Interior Elevation sheet shows conceptual interior wall elevations for the Kitchen, Bathrooms, Utility Room as well as built-ins, fireplaces and other unique interior features as per design. (Interior elevations may not be available for all stock plans.)
ELECTRICAL PLAN - The Electrical Plan sheet shows suggested wiring and location of fixtures (lighting, ceiling fans, etc.), switches and outlets. This plan does not contain diagrams detailing how all wiring should be run, or how circuits should be engineered. Your electrician should work out these details.

What's Not Included

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required
