Plan 46463LA
EXCLUSIVE
New American House Plan with Home Office and 2 Master Suites
Heated S.F.
4,115
Beds
4
Baths
3
Stories
2
Cars
3
Flyer
What's Included
Plan Details
  • Steeply-pitched gables, finished with a metal roof, top this New American house plan. An 8'-deep front porch welcomes you inside.
  • Both the formal and family entrances offer easy access to the mudroom and a powder bath. To the right of the entryway, a dining room (or flex space) can be found.
  • Tall ceilings soar above the family room, which opens to the kitchen and back porch with a built-in grill. Once in the butler's pantry, a pocket door reveals a large walk-in pantry with an island and natural light.
  • The main-level owner's suite features a sitting nook with a coffee bar, large closet, and access to the laundry room through the 5-fixture bathroom.
  • A second owner's suite is located upstairs, while bedrooms 2 and 3 share the hall bath. A home office and bonus room complete the second level.
What's Included
  • Floor plans with window and door schedules
  • Roof plan
  • Elevations
  • Front and rear perspectives on some (but not all) plans
  • Building section, eave detail and typical stair detail
  • Interior perspectives and elevations
  • Electrical plans
  • Foundation plan
  • Floor framing plans
  • Ceiling framing plans
  • Roof framing plan
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

New American House Plan with Home Office and 2 Master Suites

  • 4,115

    Heated s.f.

  • 4

    Beds

  • 3

    Baths

  • 2

    Floors

  • 3

    Car garage

Floor Plan

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total: 4,115 sq. ft.
  • 1st Floor: 2,346 sq. ft.
  • 2nd Floor: 1,769 sq. ft.

Dimensions

  • Width: 56' 0"
  • Depth: 87' 0"
  • Max ridge height: 35' 0"

Beds/Baths

  • Bedrooms: 4
  • Full bathrooms: 3

Garage

  • Type: Attached
  • Area: 795 sq. ft.
  • Count: 3 Cars
  • Entry Location: Side

Foundation Type

    • Standard Foundations: Crawl
    • Optional Foundations: Walkout, Slab, Daylight, Basement

Exterior Walls

  • Standard Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 10' 0" Second Floor / 9' 0"

Roof

  • Primary Pitch: 9 on 12
  • Framing Type: Stick
