One-level French Country Home Plan with Split-bed Layout

Plan 510217WDY

  • 4,072

    Heated s.f.

  • 4

    Beds

  • 3.5

    Baths

  • 1

    Stories

  • 3

    Cars

  • Steeply-pitched rooflines top this brick-clad, French Country home plan where homeowners can enjoy one-level living.
  • Step inside to find a sizable home office to the left of the foyer. A few steps further and you'll discover a living room with a grand fireplace and 3 windows overlooking the screened porch / patio.
  • The gourmet kitchen invites you to expand your culinary skills, complete with an eating bar at the island, butler's pantry / walk-in pantry, and a large range. Minimal walls allow you to move easily into the dining area and adjoining game room.
  • The master bedroom is tucked behind the 3-car garage for the utmost privacy and enjoys a large bathroom with his and hers closets. One of the closets leads to the laundry room as an added bonus.
  • Three secondary bedrooms with walk-in closets line the right side of the home; two bedrooms share a Jack-and-Jill bath.

This house plan set consists of the following elements:


  • Cover Sheet
  • Dimensioned Floor Plans w/ Notes & Details (if more than single level, dimensioned floor plan sheets are included for each level)
  • Exterior Elevations w/ Details
  • Building Section and Roof Plan w/ Trim Details
  • Additional Building Notes and Details
  • Electrical Layout
  • Foundation Plan
  • Foundation Details and Notes

These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Floor Plan

Main Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
One-level French Country Home Plan with Split-bed Layout - 510217WDY floor plan - Main Level

Plan details

Square Footage Breakdown

  • Total Heated Area: 4,072 sq. ft.
  • 1st Floor: 3,928 sq. ft.
  • Porch, Combined: 593 sq. ft.

Beds/Baths

  • Bedrooms: 4
  • Full bathrooms: 3
  • Half bathrooms: 1

Foundation Type

  • Standard Foundations: Slab
  • Optional Foundations: Crawl, Basement

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Dimensions

  • Width: 89' 10"
  • Depth: 93' 9"
  • Max ridge height: 32' 11"

Garage

  • Type: Attached
  • Area: 1148 sq. ft.
  • Count: 3 Cars
  • Entry Location: Side

Ceiling Heights

  • Floor / Height: First Floor / 10' 0"
Room Details Ceiling Type Width Depth Height
Master Bedroom Tray 17' 7" 16' 8" 10' 0" to 11' 4"
Great Room Vaulted 22' 4" 20' 8" 16' 7"
Media Room Flat 17' 8" 15' 5" 12' 0"
Dining Room Flat 17' 8" 9' 7" 12' 0"

Roof Details

  • Primary Pitch: 12 on 14
  • Framing Type: Stick

Architectural Style

Special features

One-level French Country Home Plan with Split-bed Layout

  • 4,072

    Heated s.f.

  • 4

    Beds

  • 3.5

    Baths

  • 1

    Floors

  • 3

    Car garage

Buy This Plan
  • 5 Sets $1,500
  • 8 Sets $1,600
  • PDF - Single-Build $1,850
  • 5 Sets + PDF $2,100
  • CAD + PDF - Unlimited Build $2,850
  • View all purchase option online

About This Plan

  • Steeply-pitched rooflines top this brick-clad, French Country home plan where homeowners can enjoy one-level living.
  • Step inside to find a sizable home office to the left of the foyer. A few steps further and you'll discover a living room with a grand fireplace and 3 windows overlooking the screened porch / patio.
  • The gourmet kitchen invites you to expand your culinary skills, complete with an eating bar at the island, butler's pantry / walk-in pantry, and a large range. Minimal walls allow you to move easily into the dining area and adjoining game room.
  • The master bedroom is tucked behind the 3-car garage for the utmost privacy and enjoys a large bathroom with his and hers closets. One of the closets leads to the laundry room as an added bonus.
  • Three secondary bedrooms with walk-in closets line the right side of the home; two bedrooms share a Jack-and-Jill bath.

Floor Plans

  • Main Level

Plan Details

Square Footage Breakdown

  • Total Heated Area: 4,072 sq. ft.
  • 1st Floor: 3,928 sq. ft.
  • Porch, Combined: 593 sq. ft.

Beds/Baths

  • Bedrooms: 4
  • Full bathrooms: 3
  • Half bathrooms: 1

Foundation Type

    • Standard Foundations: Slab
    • Optional Foundations: Crawl, Basement

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Dimensions

  • Width: 89' 10"
  • Depth: 93' 9"
  • Max ridge height: 32' 11"

Garage

  • Type: Attached
  • Area: 1148 sq. ft.
  • Count: 3 Cars
  • Entry Location: Side

Ceiling Heights

  • Floor / Height: First Floor / 10' 0"

Roof

  • Primary Pitch: 12 on 14
  • Framing Type: Stick
