Plan 39303ST
One-story Craftsman Home Plan with a Split Bedroom Layout
Heated S.F.
1,971
Beds
3
Baths
2
Stories
1
Cars
2
What's Included
Floor Plan
PRINT PLANS
Main Level
Reverse Floor Plan
One-story Craftsman Home Plan with a Split Bedroom Layout - 39303ST floor plan - Main Level
Unfinished Basement
Reverse Floor Plan
One-story Craftsman Home Plan with a Split Bedroom Layout - 39303ST floor plan - Unfinished Basement
Plan Details
  • This one-story, 3-bed Craftsman house plan has an exterior that showcases brick, stone, shakes and a large front porch.
  • A corner fireplace, open staircase, island with seating and multiple windows decorate the large open concept living space.
  • The study accommodates the new “work from home” trend and split bedrooms offer privacy to the master suite with a large walk-in closet and master bath with double bowl vanity, linen cabinet, and oversized shower.
  • A full basement is standard with this home plan offering the ability to expand the family activities to include a lower level finished area.
What's Included
  • General notes and specifications
  • Front, rear and side elevations at (1/4" scale)
  • Foundation plan (1/4" scale) indicating beam and column sizes along with lower level framing
  • Reinforced foundation and footing details
  • First floor plan (1/4" scale) includes all necessary framing information, window rough openings, beam sizes and framing details for specialized areas
  • Stairs, sections, cabinet layouts, window flashing and miscellaneous details necessary for understanding of construction methods
  • Roof plan (1/8" scale) indicating pitches and wall height as well as truss profiles indicating heel heights and raised ceiling areas
  • Wall section indicating standard materials and detailing for typical wall construction
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

One-story Craftsman Home Plan with a Split Bedroom Layout

  • 1,971

    Heated s.f.

  • 3

    Beds

  • 2

    Baths

  • 1

    Floors

  • 2

    Car garage

Floor Plan

  • Main Level

  • Unfinished Basement

Plan Details

Square Footage Breakdown

  • Total: 1,971 sq. ft.
  • 1st Floor: 1,971 sq. ft.

Dimensions

  • Width: 58' 2"
  • Depth: 57' 9"
  • Max ridge height: 22' 0"

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2

Garage

  • Type: Attached
  • Area: 491 sq. ft.
  • Count: 2 Cars
  • Entry Location: Front

Foundation Type

    • Standard Foundations: Basement
    • Optional Foundations: Crawl, Slab, Walkout

Exterior Walls

  • Standard Type(s): 2x4

Ceiling Heights

  • Floor / Height: First Floor / 9' 1"

Roof

  • Primary Pitch: 7 on 12
  • Secondary Pitch: 10 on 12
  • Framing Type: Truss
