Rectangular Barndominium with L-Shaped Porch and Drive-Through Garage

Plan 135083GRA

  • 2,511

    Heated s.f.

  • 4

    Beds

  • 3

    Baths

  • 2

    Stories

  • 3

    Cars

  • This barndominium has an efficient and budget-friendly rectangular footprint. A porch wraps around the front-left corner and has access to the home from both sides.
  • Step inside and you are greeted with an open floor plan that is open above. The kitchen island is massive and gives you seating for casual meals.
  • There are two bedrooms on the main floor as well as a laundry/mudroom off the garage entry.
  • Upstairs, a loft overlooks the living room below and two bedrooms line the back of the home.
  • On the garage side, two bays have access to the front and an extra-wide door on the back gives you drive-through access.
  • The exterior finish is spec'd for corrugated metal siding.

  • All elevations
  • Fully Dimensioned Floor Plans
  • Roof Plan & Sections
  • Foundation plan
  • General Notes
  • Suggested Electrical Layout
These items are NOT included:
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Floor Plan

Main Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Rectangular Barndominium with L-Shaped Porch and Drive-Through Garage - 135083GRA floor plan - Main Level

2nd Floor

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Rectangular Barndominium with L-Shaped Porch and Drive-Through Garage - 135083GRA floor plan - 2nd Floor
