Plan 59985ND Rugged Craftsman Home Plan with Home Theater in Finished Walkout Basement

5,051 4-6 5 2 3
Print
Compare
...
All plans are copyrighted by our designers. Photographed homes may include modifications made by the homeowner with their builder.

Rugged Craftsman Home Plan with Home Theater in Finished Walkout Basement

Plan 59985ND

  • 5,051

    Heated s.f.

  • 4-6

    Beds

  • 5

    Baths

  • 2

    Stories

  • 3

    Cars

  • This beautiful rustic, split-bedroom home plan offers a very family oriented layout. A great room with a fireplace and built-ins is open to the kitchen and hearth room and has access to the grilling porch. The kitchen features a prep island and a corner walk-in pantry.
  • The hearth room/breakfast room is on a 45 degree angle and has a fireplace and access to the grilling porch.
  • The master suite has a 10' boxed ceiling and private access to the grilling porch with the master bathroom offering a large corner whirlpool tub , a glass shower with a seat, and a huge walk-in closet with a fold down ironing board.
  • Upstairs the theater balcony overlooks the great room and there's a bedroom, an optional bedroom, a full bath and a huge media/bonus room.
  • The lower floor offers plenty more with a large den with a fireplace, built-ins and access to the covered porch. There's also another full kitchen and a 5th bedroom with a full bath. Next to the stairs is a theater room/storage/exercise room. Guests or in-laws will feel most taken care of in their suite with a large walk-in closet, and private bath with whirlpool tub, a large corner shower and even a nearby 2nd laundry room.
  • Related Plan: Eliminate the finished walkout  basement with house plan 60715ND.

Each plan set includes the following:

  • Foundation Plan** (1/4″ or 1/2″ = 1′)
  • Floor Plans (1/4″= 1′)
  • Set of Elevations (1/4″= 1′)
  • Miscellaneous Details (3/4″ = 1′)
  • An electrical diagram showing a birdseye view of rooms with lights, fans to switches
These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Floor Plan

Main Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Rugged Craftsman Home Plan with Home Theater in Finished Walkout Basement - 59985ND floor plan - Main Level

Second Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Rugged Craftsman Home Plan with Home Theater in Finished Walkout Basement - 59985ND floor plan - Second Level

Lower Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Rugged Craftsman Home Plan with Home Theater in Finished Walkout Basement - 59985ND floor plan - Lower Level

Plan details

Square Footage Breakdown

  • Total Heated Area: 5,051 sq. ft.
  • Lower Level: 2,169 sq. ft.
  • 1st Floor: 2,222 sq. ft.
  • 2nd Floor: 661 sq. ft.
  • Porch, Combined: 755 sq. ft.
  • Bonus: 460 sq. ft.

Beds/Baths

  • Bedrooms: 4, 5, or 6
  • Full bathrooms: 5

Foundation Type

  • Standard Foundations: Daylight, Walkout

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Dimensions

  • Width: 67' 3"
  • Depth: 75' 5"
  • Max ridge height: 32' 0"

Garage

  • Type: Attached
  • Area: 743 sq. ft.
  • Count: 3 Cars
  • Entry Location: Side

Ceiling Heights

  • Floor / Height: Lower Level / 9' 0" First Floor / 9' 0" Second Floor / 9' 0"

Roof Details

  • Primary Pitch: 10 on 12
  • Secondary Pitch: 2 on 12
  • Framing Type: Stick

Architectural Style

Special features

Plan Collections

Rugged Craftsman Home Plan with Home Theater in Finished Walkout Basement

  • 5,051

    Heated s.f.

  • 4-6

    Beds

  • 5

    Baths

  • 2

    Floors

  • 3

    Car garage

Buy This Plan
  • PDF - Single-Build $2,050
  • 5 Sets $2,150
  • 5 Sets + PDF $2,400
  • PDF - Unlimited Build $2,750
  • CAD Unlimited + PDF $4,100
  • View all purchase option online

About This Plan

  • This beautiful rustic, split-bedroom home plan offers a very family oriented layout. A great room with a fireplace and built-ins is open to the kitchen and hearth room and has access to the grilling porch. The kitchen features a prep island and a corner walk-in pantry.
  • The hearth room/breakfast room is on a 45 degree angle and has a fireplace and access to the grilling porch.
  • The master suite has a 10' boxed ceiling and private access to the grilling porch with the master bathroom offering a large corner whirlpool tub , a glass shower with a seat, and a huge walk-in closet with a fold down ironing board.
  • Upstairs the theater balcony overlooks the great room and there's a bedroom, an optional bedroom, a full bath and a huge media/bonus room.
  • The lower floor offers plenty more with a large den with a fireplace, built-ins and access to the covered porch. There's also another full kitchen and a 5th bedroom with a full bath. Next to the stairs is a theater room/storage/exercise room. Guests or in-laws will feel most taken care of in their suite with a large walk-in closet, and private bath with whirlpool tub, a large corner shower and even a nearby 2nd laundry room.
  • Related Plan: Eliminate the finished walkout  basement with house plan 60715ND.

Floor Plans

  • Main Level

  • Second Level

  • Lower Level

Plan Details

Square Footage Breakdown

  • Total Heated Area: 5,051 sq. ft.
  • Lower Level: 2,169 sq. ft.
  • 1st Floor: 2,222 sq. ft.
  • 2nd Floor: 661 sq. ft.
  • Porch, Combined: 755 sq. ft.
  • Bonus: 460 sq. ft.

Beds/Baths

  • Bedrooms: 4, 5, or 6
  • Full bathrooms: 5

Foundation Type

    • Standard Foundations: Daylight, Walkout

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Dimensions

  • Width: 67' 3"
  • Depth: 75' 5"
  • Max ridge height: 32' 0"

Garage

  • Type: Attached
  • Area: 743 sq. ft.
  • Count: 3 Cars
  • Entry Location: Side

Ceiling Heights

  • Floor / Height: Lower Level / 9' 0" First Floor / 9' 0" Second Floor / 9' 0"

Roof

  • Primary Pitch: 10 on 12
  • Secondary Pitch: 2 on 12
  • Framing Type: Stick
