Plan 25808GE
Rustic Mountain Cottage Under 1200 Square Feet with Split Bedroom Layout
Heated S.F.
1,197
Beds
2
Baths
2
Stories
1
Cars
1
What's Included
Plan Details
  • This rustic mountain cottage gives you 2 beds, 2 baths, and 1,197 square feet of heated living space. The exterior has multiple gables, a decorative dormer, and a mix of shingles, stone and wood.
  • Step inside and you are greeted by a vaulted open concept layout with the kitchen, dining and living room combined into one functional space.
  • The bedrooms are split for your privacy with the vaulted master on the right with a walk-in closet and Bed 2 on the left with a tray vaulted ceiling.
  • A 1-car garage is on the left and has a dedicated storage room in the back.
What's Included
  • Exterior elevations: Included are front, rear, left and right side views of the exterior of the house. Exterior materials, construction details and measurements are also noted.
  • Foundation Plan: Includes layout of foundation support walls, plus excavated and unexcavated areas, if applicable.
  • Detailed Floor Plans: These plans show the layout of each floor of the house, including room dimensions, window and doors sizes and keys for cross section details provided later in the plans. Engineered floor joist, ceiling joist and roof plans are not included in some plans. Local engineers or manufacturing engineers are widely available to supply the services that apply to local geographic conditions.
  • Interior Details: These drawings show the specific details and design of special interior features.
  • Roof Plan: Includes the overall layout for roof construction. If trusses are used, we recommend using a local truss manufacturer to ensure compliance with local codes and regulations.
  • Cross Section Detail: Important changes in floor, ceiling and roof heights or the relationship of one level to another are called out. Exterior details such as railing and banding may also be shown.
  • Electrical: Electrical floor plan schematics for 1st and 2nd floors.
  • Plans include wall and cornice sections, general foundation sections and details.
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Framing plans
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
