Rustic Ranch Plan with Walkout Basement and Home Theater

Plan 135186GRA

  • 2,220

    Heated s.f.

  • 3

    Beds

  • 2.5

    Baths

  • 1

    Stories

  • 2

    Cars

  • This Rustic Ranch home plan features a rectangular footprint topped by a gabled, metal roof.
  • The oversized double garage attaches to the left side of the home with a spacious laundry / mudroom combo awaiting to greet you.
  • In the center, you will find a cathedral ceiling above the open great room, dining area, and kitchen. An island maximizes meal prep space and provides a flush eating bar for casual meals.
  • The master bedroom features a sizable ensuite with a custom tile shower and walk-in closet. Bedrooms 2 and 3 each have a walk-in closet and share a full bath.
  • A secondary gathering space can be found downstairs with patio access and a wet bar, and a home theatre provides an ideal spot for movie night.

  • All elevations
  • Fully Dimensioned Floor Plans
  • Roof Plan & Sections
  • Foundation plan
  • General Notes
  • Suggested Electrical Layout
These items are NOT included:
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Rustic Ranch Plan with Walkout Basement and Home Theater - 135186GRA floor plan - Main Level
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Rustic Ranch Plan with Walkout Basement and Home Theater - 135186GRA floor plan - Lower Level

Rustic Ranch Plan with Walkout Basement and Home Theater

  • 2,220

    Heated s.f.

  • 3

    Beds

  • 2.5

    Baths

  • 1

    Floors

  • 2

    Car garage

Floor Plan

  • Main Level

  • Lower Level

Plan Details

Square Footage Breakdown

  • Total: 2,220 sq. ft.
  • 1st Floor: 2,220 sq. ft.

Dimensions

  • Width: 84' 0"
  • Depth: 37' 0"
  • Max ridge height: 18' 10"

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2
  • Half bathrooms: 1

Garage

  • Type: Attached
  • Area: 888 sq. ft.
  • Count: 2 Cars
  • Entry Location: Front

Foundation Type

    • Optional Foundations: Slab, Walkout, Crawl, Basement

Exterior Walls

  • Standard Type(s): 2x6

Ceiling Heights

  • Floor / Height: Lower Level / 9' 0" First Floor / 9' 0"

Roof

  • Primary Pitch: 6 on 12
  • Framing Type: Truss
