This house plan has the following pages:
Page 1 Cover Sheet with abbreviations, rendering, sheet index
Page 2 Foundation Plan and Details
Page 3 Detailed main floor plan(includes window sizes, ceiling joist directions, plumbing fixture locations, etc.)
Page 4 Detailed bonus floor plan(includes window sizes, ceiling joist directions, plumbing fixture locations, etc.)
Page 5 Front and rear exterior views with additional details
Page 6 Right and left exterior views with additional details
Page 7 Cross Section & kitchen cabinet views
Page 8 Roof plan and span charts with additional details
Page 9 Electrical plans & notes/ legend
Page N1 Code Information
Page N2 Code Information
Page N3 Code Information
Page N4 Energy Code Information
These items are NOT included:
- Architectural or Engineering Stamp - handled locally if required
- Site Plan - handled locally when required
- Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
- Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
- Energy calculations - handled locally when required
