Traditional Design with Alternate

Plan 22083SL

  • 1,902

    Heated s.f.

  • 3

    Beds

  • 2

    Baths

  • 2

    Stories

  • 2

    Cars

  • This 3 bedroom house plan has a welcoming covered front porch and features an open floor plan.
  • The kitchen features counter seating and a nearby breakfast nook with bay window.
  • The family room is open to the kitchen and has a fireplace.
  • The dining room and living room flank the entry.
  • The 2-car garage is front-entry and has a workshop or storage area.
  • Related Plan: For a smaller version see house plan 22093SL (1,578 sq. ft.).

Each plan set includes the following:

  • Foundation plan
  • Fully dimensioned floor plans
  • Exterior elevations
  • Roof plan
  • Electrical plan
  • Cabinet elevations
  • Building section
  • Typical stair and wall sections and other related details
These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Floor Plan

Main Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Traditional Design with Alternate - 22083SL floor plan - Main Level

2nd Floor

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Traditional Design with Alternate - 22083SL floor plan - 2nd Floor

Plan details

Square Footage Breakdown

  • Total Heated Area: 1,902 sq. ft.
  • 1st Floor: 900 sq. ft.
  • 2nd Floor: 1,002 sq. ft.

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2

Foundation Type

  • Standard Foundations: Basement

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Dimensions

  • Width: 50' 0"
  • Depth: 37' 8"
  • Max ridge height: 26' 6"

Garage

  • Type: Attached
  • Area: 526 sq. ft.
  • Count: 2 Cars
  • Entry Location: Front

Ceiling Heights

  • Floor / Height: First Floor / 8' 0" Second Floor / 8' 0"

Roof Details

  • Primary Pitch: 7 on 12
  • Secondary Pitch: 5 on 12
  • Framing Type: Truss

Architectural Style

Special features

Traditional Design with Alternate

  • 1,902

    Heated s.f.

  • 3

    Beds

  • 2

    Baths

  • 2

    Floors

  • 2

    Car garage

Buy This Plan
  • 5 Sets $665
  • 8 Sets $680
  • PDF - Single-Build $780
  • CAD - Single-Build $860
  • PDF - Unlimited Build $2,080
  • CAD - Unlimited Build $2,160
  • View all purchase option online

About This Plan

  • This 3 bedroom house plan has a welcoming covered front porch and features an open floor plan.
  • The kitchen features counter seating and a nearby breakfast nook with bay window.
  • The family room is open to the kitchen and has a fireplace.
  • The dining room and living room flank the entry.
  • The 2-car garage is front-entry and has a workshop or storage area.
  • Related Plan: For a smaller version see house plan 22093SL (1,578 sq. ft.).

Floor Plans

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total Heated Area: 1,902 sq. ft.
  • 1st Floor: 900 sq. ft.
  • 2nd Floor: 1,002 sq. ft.

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2

Foundation Type

    • Standard Foundations: Basement

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Dimensions

  • Width: 50' 0"
  • Depth: 37' 8"
  • Max ridge height: 26' 6"

Garage

  • Type: Attached
  • Area: 526 sq. ft.
  • Count: 2 Cars
  • Entry Location: Front

Ceiling Heights

  • Floor / Height: First Floor / 8' 0" Second Floor / 8' 0"

Roof

  • Primary Pitch: 7 on 12
  • Secondary Pitch: 5 on 12
  • Framing Type: Truss
Plan 22083SL
View this and more for this plan by visiting www.architechtecturaldesigns.com/22083SL
|
