Plan 89293AH

Traditional Ranch Duplex Home Plan

Heated S.F.
2,514
Units
2
Width
Depth

Floor Plan

Plan 89293AH

Main Level
Main Level

Plan 89293AH

M-F 9am-5pm EST |

1-203-761-8500

Main Level

Plan 89293AH: Traditional Ranch Duplex Home Plan - Floor Plan - Main Level - Ranch, Traditional

Plan Details

  • This traditional ranch duplex was designed with two identical units to create a plan that is easy as well as affordable to build.
  • As you enter the foyer you'll love the open floor plan where the living room, dining room and kitchen all flow together to create a living space that's impressive for a 1250 square foot unit.
  • Each unit has a master suite complete with walk-in closet, two additional bedrooms and a main floor laundry located off the garage.
  • Additional amenities include a covered porch off the kitchen, a spacious front porch, a breakfast bar that overlooks the dining area and a two-stall garage.
Unit A
Heated Area
1,257Sq. Ft.
1257 Sq. Ft. 1st
Beds
3Beds
Baths
2Full Baths
Cars
Attached
426 Sq. Ft.
Dimensions
40'width
49'depth
21' 6"height
Unfinished Areas
426 Sq. Ft. Garage
Unit B
Heated Area
1,257Sq. Ft.
1257 Sq. Ft. 1st
Beds
3Beds
Baths
2Full Baths
Cars
Attached
426 Sq. Ft.
Dimensions
40'width
49'depth
21' 6"height
Unfinished Areas
426 Sq. Ft. Garage
