Plan 3919ST
Tranquil Family Home Plan
Heated S.F.
2,338
Beds
4
Baths
2.5
Stories
2
Cars
2
What's Included
Plan Details
  • With its second-floor loft, a great location for computer workstations, this tranquil European-style cottage works well for the family with children.
  • High, sloped ceilings open up both the foyer and the great room. A fireplace adds warmth not only to the great room, but also to the breakfast room and kitchen.
  • In a secluded wing, the master suite has an upscale bathroom with his and her vanities, a garden spa tub, separate shower and walk-in closet.
  • Walk-in closets offer storage space in the family bedrooms upstairs. Bonus space over the garage provides an additional option for children's activities.
  • A walk-in pantry, laundry room and half-bath, all near the kitchen, complete the design.
  • Ceilings: 9' first floor; 8' second floor.
  • Foundation options: basement or daylight basement. Specify when ordering.
What's Included
  • General notes and specifications
  • Front, rear and side elevations at (1/4" scale)
  • Foundation plan (1/4" scale) indicating beam and column sizes along with lower level framing
  • Reinforced foundation and footing details
  • First floor plan (1/4" scale) includes all necessary framing information, window rough openings, beam sizes and framing details for specialized areas
  • Stairs, sections, cabinet layouts, window flashing and miscellaneous details necessary for understanding of construction methods
  • Roof plan (1/8" scale) indicating pitches and wall height as well as truss profiles indicating heel heights and raised ceiling areas
  • Wall section indicating standard materials and detailing for typical wall construction
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

Tranquil Family Home Plan

  • 2,338

    Heated s.f.

  • 4

    Beds

  • 2.5

    Baths

  • 2

    Floors

  • 2

    Car garage

Floor Plan

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total: 2,338 sq. ft.
  • 1st Floor: 1,633 sq. ft.
  • 2nd Floor: 705 sq. ft.

Dimensions

  • Width: 58' 6"
  • Depth: 49' 0"
  • Max ridge height: 27' 3"

Beds/Baths

  • Bedrooms: 4
  • Full bathrooms: 2
  • Half bathrooms: 1

Garage

  • Type: Attached
  • Area: 390 sq. ft.
  • Count: 2 Cars
  • Entry Location: Side

Foundation Type

    • Standard Foundations: Basement, Daylight

Exterior Walls

  • Standard Type(s): 2x4

Ceiling Heights

  • Floor / Height: First Floor / 9' 0" Second Floor / 8' 0"

Roof

  • Primary Pitch: 8 on 12
  • Secondary Pitch: 12 on 12
  • Framing Type: Truss
