Plan 623078DJ
Transitional House Plan with Stucco Exterior and Steep Rooflines
Heated S.F.
1,680
Beds
3-4
Baths
2 - 3
Stories
1
Cars
2
Tour
Flyer
Videos
What's Included
Floor Plan
PRINT PLANS
Main Level
Reverse Floor Plan
Transitional House Plan with Stucco Exterior and Steep Rooflines - 623078DJ floor plan - Main Level
Finished Basement Option (+$250)
Reverse Floor Plan
Transitional House Plan with Stucco Exterior and Steep Rooflines - 623078DJ floor plan - Finished Basement Option (+$250)
Plan Details
  • This transitional house plan with stucco siding paired with a metal roof and steep rooflines has great curb appeal. A front courtyard and covered porch greet guests into the home.
  • Inside, the open layout of the great room, kitchen, and dining room - all under a soaring cathedral ceiling - gives you a great space for entertaining friends and family.
  • The great room is warmed by a fireplace with a built-in to the right and can be seen from the kitchen with large island with a snack bar and a huge walk-in pantry. The dining room has direct access to the rear covered porch through a sliding glass door.
  • The master bedroom also lies under its own cathedral ceiling. The master bathroom includes his/her vanities, a walk-in shower, and a walk-in closet. Two additional bedrooms can be found on the right side of the home.
  • The 2-car garage accesses the home through a convenient mudroom that includes a bench and lockers.
  • The finished layout option for the basement (+$250) adds a family room with a fireplace, a wet bar, an exercise room with a sauna, and an additional bedroom.
What's Included
  • Cover Sheet: Shows the front elevation and typical notes and requirements.
  • Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurement
  • Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor
  • Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible.
  • Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
  • Roof Plan
  • Typical Wall Section
  • Typical Stair Section
  • Cabinets Elevations
Sample Plan
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

Transitional House Plan with Stucco Exterior and Steep Rooflines

  • 1,680

    Heated s.f.

  • 3-4

    Beds

  • 2 - 3

    Baths

  • 1

    Floors

  • 2

    Car garage

Floor Plan

  • Main Level

  • Finished Basement Option (+$250)

Plan Details

Square Footage Breakdown

  • Total: 1,680 sq. ft.
  • 1st Floor: 1,680 sq. ft.

Dimensions

  • Width: 67' 4"
  • Depth: 49' 8"
  • Max ridge height: 25' 0"

Beds/Baths

  • Bedrooms: 3 or 4
  • Full bathrooms: 2 or 3

Garage

  • Type: Attached
  • Area: 600 sq. ft.
  • Count: 2 Cars
  • Entry Location: Front

Foundation Type

    • Standard Foundations: Basement
    • Optional Foundations: Walkout, Slab, Crawl

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Ceiling Heights

  • Floor / Height: Lower Level / 9' 0" First Floor / 9' 0"

Roof

  • Primary Pitch: 12 on 12
  • Secondary Pitch: 4 On 12; 6 On 12; 14 on 12
  • Framing Type: Truss
