Transitional Ranch House Plan with Coffered Great Room - 2559 Sq Ft
Heated S.F.
2,559
Beds
4
Baths
3.5
Stories
1
Cars
3
What's Included
Plan Details
  • This Transitional ranch house plan gives you 2,559 square feet of heated living space which includes the 329 square foot bonus room above the 633 square foot 3-car garage.
  • The bedrooms are clustered on the right side of the home including the master suite with large walk-in closet and windows letting in light from the back.
  • The great room has a coffered ceiling and a fireplace and is open to the kitchen. The dining room is also open to the kitchen and has views to the back.
  • Related Plan: Get an alternate version with house plan 28022J.
What's Included
  • Foundation plan with details
  • Detailed floor plan (includes window sizes, ceiling joist directions, plumbing fixture locations, etc.)
  • Four exterior views (front, rear, right, left)
  • Roof plan (birds eye view of roof)
  • Building section
  • Wall section
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
