Plan 59773ND
Two Single-Family Victorian Home Plans with Shared Porte Cochere
Heated S.F.
6,044
Units
2
Width
113' 4"
Depth
82'
Cars
4
What's Included
Plan Details
  • This duplex house plan gives you matching 2-story units with 4 bed and 3.5 baths connected by a shared porte-cochere.
  • Each unit gives you 3,022 square feet of heated living (1,796 sq. ft. on the first floor and 1,226 sq. ft. on the second floor) and a 2-car garage (594 sq. ft.) located in back.
Unit A
3,022 Sq. Ft.
1796 Sq. Ft. 1st Floor
1226 Sq. Ft. 2nd Floor
4 Beds
3 Full Baths
1 Half Bath
2 Vehicle
Attached
594 Sq. Ft.
56' 8" w 82' d 34' h
Unit B
3,022 Sq. Ft.
1796 Sq. Ft. 1st Floor
1226 Sq. Ft. 2nd Floor
4 Beds
3 Full Baths
1 Half Bath
2 Vehicle
Attached
549 Sq. Ft.
65' 8" w 82' d 34' h
What's Included
  • Foundation Plan** (1/4″ or 1/2″ = 1′)
  • Floor Plans (1/4″= 1′)
  • Set of Elevations (1/4″= 1′)
  • Miscellaneous Details (3/4″ = 1′)
  • An electrical diagram showing a birdseye view of rooms with lights, fans to switches
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

Two Single-Family Victorian Home Plans with Shared Porte Cochere

  • 6,044

    Heated s.f.

  • 2

    Units

  • 113' 4"

    Width

  • 82'

    Depth

Floor Plan

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total: 6,044 sq. ft.
  • 1st Floor: 3,592 sq. ft.
  • 2nd Floor: 2,452 sq. ft.

Dimensions

  • Width: 113' 4"
  • Depth: 82' 0"
  • Max ridge height: 34' 4"

Beds/Baths

  • Bedrooms: 8
  • Full bathrooms: 6
  • Half bathrooms: 2

Garage

  • Type: Attached
  • Area: 1098 sq. ft.
  • Count: 4 Cars
  • Entry Location: Side

Foundation Type

    • Standard Foundations: Crawl, Slab
    • Optional Foundations: Basement, Walkout

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 9' 0" Second Floor / 8' 0"

Roof

  • Primary Pitch: 12 on 12
  • Framing Type: Stick
