Plan 36662TX Two-story European Home Plan with Game Room and Home Gym

5,413 4 4 1 3
Print
Compare
...
All plans are copyrighted by our designers. Photographed homes may include modifications made by the homeowner with their builder.

Two-story European Home Plan with Game Room and Home Gym

Plan 36662TX

  • 5,413

    Heated s.f.

  • 4

    Beds

  • 4

    Baths

  • 1

    Stories

  • 3

    Cars

  • This two-story, European home plan defines luxury with an exterior facade of stone, turrets, covered veranda, and patio. A portico that leads to three garage bays welcomes you home.
  • Inside the grand foyer, your eyes are drawn to the wide sweeping stairway, which sets the stage for the elegant living room, complete with floor to ceiling windows.
  • The dining room opens into the butlery with a wet bar, adjacent to the gourmet kitchen with its large pantry, state-of-the-art appliances, freestanding center island, and a winding eating bar that seamlessly separates the kitchen from the breakfast and family rooms.
  • A large utility room and powder bath separate the living space from the master suite, which boasts a fireplace, bay-window sitting area, access to a private patio, deluxe master bath, and an exercise room.
  • Upstairs, a cat walk hallway offers views of the first-floor plan below and shares space with a loft. Two family bedrooms share a Jack-and-Jill bath, while a third bedroom has a full bath. A sizable game room finishes off the second level.

Plan set includes the following:


1.       Cover sheet

2.       Foundation Plan

3.       First floor fully dimensioned floor plan with notes - All requisite aspects of the floor plan are precise, though the details of flooring material and non-structural aesthetics are left to the discretion of the buyer.

4.       Second floor fully dimensioned floor plan with notes - Exact flooring materials, appliance selection and non-structural aesthetics are left to the discretion of the buyer.

5.       First floor lighting and electrical plan - On this sheet you have a schematic of the lights, electrical plugs, phone locations, and code items such as smoke detectors.

6.       Second floor lighting and electrical plan - On this sheet you have a schematic of the lights, electrical plugs, phone locations, and code items such as smoke detectors.

7.       Front & rear elevations with notes-detailed drawings of the left and right sides of the home along with any notes and exterior dimensions that may be required to complete construction. The elevations show the contractor's exterior materials, general architectural design intent, types of openings and other details. All of our elevations are drawn to ¼ scale.

8.       Left and right elevations with notes - detailed drawings of the left and right sides of the home along with any notes and exterior dimensions that may be required to complete construction. The elevations show the contractor's exterior materials, general architectural design intent, types of openings and other details. All of our elevations are drawn to ¼ scale.

9.       Roof plan - This sheet roof plan is an integral piece of a well-designed set of elevations. Roof cuts are shown to demonstrate how the architectural design is intended to make the elevation aesthetically pleasing to the eye.

10.   Sections page

11.   Standard detail sheets on construction. These sheets are used to cover a broad range of many everyday situations that may occur on a construction site. The detail sheets are current and accurate to the area and time of which the house was originally designed.

These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Floor Plan

Main Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Two-story European Home Plan with Game Room and Home Gym - 36662TX floor plan - Main Level

2nd Floor

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Two-story European Home Plan with Game Room and Home Gym - 36662TX floor plan - 2nd Floor

Plan details

Square Footage Breakdown

  • Total Heated Area: 5,413 sq. ft.
  • 1st Floor: 3,440 sq. ft.
  • 2nd Floor: 1,973 sq. ft.

Beds/Baths

  • Bedrooms: 4
  • Full bathrooms: 4

Foundation Type

  • Standard Foundations: Slab

Exterior Walls

  • Standard Type(s): 2x6

Dimensions

  • Width: 132' 0"
  • Depth: 90' 0"
  • Max ridge height: 34' 0"

Garage

  • Type: Attached
  • Area: 1373 sq. ft.
  • Count: 3 Cars
  • Entry Location: Courtyard, Rear, Side

Ceiling Heights

  • Floor / Height: First Floor / 10' 0" Second Floor / 9' 0"

Roof Details

  • Framing Type: Stick

Architectural Style

Special features

Two-story European Home Plan with Game Room and Home Gym

  • 5,413

    Heated s.f.

  • 4

    Beds

  • 4

    Baths

  • 1

    Floors

  • 3

    Car garage

Buy This Plan
  • PDF - Single-Build $2,420
  • 5 Sets $2,620
  • CAD + PDF - Single Build $3,630
  • View all purchase option online

About This Plan

  • This two-story, European home plan defines luxury with an exterior facade of stone, turrets, covered veranda, and patio. A portico that leads to three garage bays welcomes you home.
  • Inside the grand foyer, your eyes are drawn to the wide sweeping stairway, which sets the stage for the elegant living room, complete with floor to ceiling windows.
  • The dining room opens into the butlery with a wet bar, adjacent to the gourmet kitchen with its large pantry, state-of-the-art appliances, freestanding center island, and a winding eating bar that seamlessly separates the kitchen from the breakfast and family rooms.
  • A large utility room and powder bath separate the living space from the master suite, which boasts a fireplace, bay-window sitting area, access to a private patio, deluxe master bath, and an exercise room.
  • Upstairs, a cat walk hallway offers views of the first-floor plan below and shares space with a loft. Two family bedrooms share a Jack-and-Jill bath, while a third bedroom has a full bath. A sizable game room finishes off the second level.

Floor Plans

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total Heated Area: 5,413 sq. ft.
  • 1st Floor: 3,440 sq. ft.
  • 2nd Floor: 1,973 sq. ft.

Beds/Baths

  • Bedrooms: 4
  • Full bathrooms: 4

Foundation Type

    • Standard Foundations: Slab

Exterior Walls

  • Standard Type(s): 2x6

Dimensions

  • Width: 132' 0"
  • Depth: 90' 0"
  • Max ridge height: 34' 0"

Garage

  • Type: Attached
  • Area: 1373 sq. ft.
  • Count: 3 Cars
  • Entry Location: Courtyard, Rear, Side

Ceiling Heights

  • Floor / Height: First Floor / 10' 0" Second Floor / 9' 0"

Roof

  • Framing Type: Stick
Plan 36662TX
View this and more for this plan by visiting www.architechtecturaldesigns.com/36662TX
|
Need Help? 800-854-7852
|
