Plan 59397ND
Vacation Retreat
Heated S.F.
2,501
Beds
1
Baths
1.5+
Stories
2
What's Included
Plan Details
  • Picture yourself on the front porch of this cozy traditional home.
  • Welcome friends inside to your beautiful foyer and retreat to the dining room for an enjoyable meal by the fire.
  • The rear porch will be perfect for those summer cookouts.
  • Retire to the secluded master suite for relaxation.
  • Put the loft to use as you see fit.
  • The front and long back porch are both 12' deep and can easily accomodate furniture creating an outdoor living area.
  • Related Plan: Replace the loft with two bedrooms with house plan 60544ND.
What's Included
  • Foundation Plan** (1/4″ or 1/2″ = 1′)
  • Floor Plans (1/4″= 1′)
  • Set of Elevations (1/4″= 1′)
  • Miscellaneous Details (3/4″ = 1′)
  • An electrical diagram showing a birdseye view of rooms with lights, fans to switches
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

Vacation Retreat

  • 2,501

    Heated s.f.

  • 1

    Beds

  • 1.5+

    Baths

  • 2

    Floors

Floor Plan

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total: 2,501 sq. ft.
  • 1st Floor: 1,786 sq. ft.
  • 2nd Floor: 715 sq. ft.

Dimensions

  • Width: 50' 0"
  • Depth: 75' 6"
  • Max ridge height: 27' 6"

Beds/Baths

  • Bedrooms: 1
  • Full bathrooms: 1
  • Half bathrooms: 2

Foundation Type

    • Standard Foundations: Crawl, Slab
    • Optional Foundations: Basement, Walkout

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 9' 0" Second Floor / 8' 0"

Roof

  • Primary Pitch: 12 on 12
  • Framing Type: Stick
