Plan 720014DA
1-Bed House Plan with Lower Level Garage
Heated S.F.
2,049
Beds
1
Baths
2
Stories
1-2
Cars
2
What's Included
Plan Details
  • Perfect for a sloped lot, this 1-bedroom house plan features a lower level garage, with ample storage space and a generous hobby room with a full bath.
  • An open gable roof sits above the front porch, which leads directly into the heart of the home.
  • L-shaped cabinets and counters wrap around an island with an eating bar in the kitchen, which provides clean views into the adjoining great room.
  • Oversized sliding doors in the great room grant access to a covered balcony, while French doors open to a sizable home office.
  • The bedroom includes a private balcony, along with walk-in closet that connects to the laundry room, as well as the 5-fixture bath.
What's Included
Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
  • Cover Sheet/Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
  • Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
  • Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
  • Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
  • Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details. Foundation types vary; please call to confirm the foundation type of the plan you are interested in.
  • Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc. Specific details such as fireplaces, stairways, decks, etc. Details are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
  • Building Section: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation.
  • Electrical Plan: A schematic layout of all lighting, switches, and electrical outlets.
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

1-Bed House Plan with Lower Level Garage

  • 2,049

    Heated s.f.

  • 1

    Beds

  • 2

    Baths

  • 1-2

    Floors

  • 2

    Car garage

Floor Plan

  • Main Level

  • Lower Level

Plan Details

Square Footage Breakdown

  • Total: 2,049 sq. ft.
  • Lower Level: 657 sq. ft.
  • 1st Floor: 1,392 sq. ft.

Dimensions

  • Width: 58' 0"
  • Depth: 38' 0"

Beds/Baths

  • Bedrooms: 1
  • Full bathrooms: 2

Garage

  • Type: Attached, Drive Under
  • Area: 935 sq. ft.
  • Count: 2 Cars
  • Entry Location: Front

Foundation Type

    • Standard Foundations: Walkout
    • Optional Foundations: Slab, Crawl, Basement

Exterior Walls

  • Standard Type(s): 2x6

Ceiling Heights

  • Floor / Height: Lower Level / 10' 0" First Floor / 9' 0"

Roof

  • Primary Pitch: 5 on 12
