1600 Square Foot Barndominium-Style House Plan with 2-Car Side-Entry Garage

Plan 135205GRA

  • 1,649

    Heated s.f.

  • 2

    Beds

  • 2.5

    Baths

  • 2

    Stories

  • 2

    Cars

  • This 1,649 square foot barndominium-style house plan is designed with 2x6 exterior walls and corrugated metal siding and gives you 2 beds, 2.5 baths and a massive 1,152 square foot 2-car side-entry garage.
  • A porch wraps around three sides of the home giving you 849 square feet of fresh air space to enjoy.
  • The front porch deposits you in the 2-story living room with corner fireplace that is open to the kitchen with double sink centered over a window looking out across the front porch. An oversized island gives you workspace and casual seating.
  • The master bedroom is conveniently located on the main level and includes a full bathroom and access to the laundry room and to the side porch.
  • Enter from the garage to find a mudroom to store your gear.
  • Upstairs, a loft overlooks the living room below and a second bedroom and a full bath with two vanities completes the floor.
  • Related Plan: Get an alternate version with house plan 135076GRA.

  • All elevations
  • Fully Dimensioned Floor Plans
  • Roof Plan & Sections
  • Foundation plan
  • General Notes
  • Suggested Electrical Layout
These items are NOT included:
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Floor Plan

Main Level

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
1600 Square Foot Barndominium-Style House Plan with 2-Car Side-Entry Garage - 135205GRA floor plan - Main Level

2nd Floor

Reverse Floor Plan
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
1600 Square Foot Barndominium-Style House Plan with 2-Car Side-Entry Garage - 135205GRA floor plan - 2nd Floor

Plan details

Square Footage Breakdown

  • Total Heated Area: 1,649 sq. ft.
  • 1st Floor: 1,080 sq. ft.
  • 2nd Floor: 569 sq. ft.
  • Porch, Combined: 849 sq. ft.

Beds/Baths

  • Bedrooms: 2
  • Full bathrooms: 2
  • Half bathrooms: 1

Foundation Type

  • Standard Foundations: Slab
  • Optional Foundations: Walkout, Crawl, Basement

Exterior Walls

  • Standard Type(s): 2x6

Dimensions

  • Width: 70' 0"
  • Depth: 52' 0"
  • Max ridge height: 23' 9"

Garage

  • Type: Attached
  • Area: 1152 sq. ft.
  • Count: 2 Cars
  • Entry Location: Side

Ceiling Heights

  • Floor / Height: First Floor / 8' 0" Second Floor / 8' 0"

Roof Details

  • Primary Pitch: 4 on 12
  • Framing Type: Truss

Architectural Style

Special features
