2133 Square Foot Mid-Century Modern House Plan with Vaulted Open Concept interior

Heated S.F.
2,133
Beds
3
Baths
2
Stories
1

Floor Plan

Plan 770505JME

Main Level
Main Level

Plan 770505JME

M-F 9am-5pm EST |

1-203-761-8500

Main Level

Plan 770505JME: 2133 Square Foot Mid-Century Modern House Plan with Vaulted Open Concept interior - Floor Plan - Main Level - Cabin, Mid Century Modern, Modern, Mountain, Northwest, Ranch, Rustic

Plan Details

  • This 2,133 square foot mid-century modern house plan gives you 3 beds, 2 baths and and a vaulted open concept interior. Deep eaves, a combination of wood and stone, and lots of glass give the home plan great curb appeal.
  • A 5'-deep covered porch supported by four timber beams gives you a great shaded fresh air space to enjoy, as does the 16' by 14' covered patio accessible from the vaulted great room with fireplace.
  • The kitchen has a double sink centered beneath a window looking out the back, and a 5' by 4' prep island with casual seating.
  • The master suite has a vaulted ceiling (9' to 11'6", left to right) and French door access to the back. Across the home, Bed 2 also has outdoor access. Laundry is conveniently located across the hall from the bathroom.
  • DELIVERY NOTE: Please allow 3 to 5 days for delivery if it includes Readable Reverse.

What's Included

  • Cover sheet
  • Foundation plan
  • Floor plans
  • Floor joist layout
  • Roof truss layout
  • Sections
  • Elevations

What's Not Included

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required.
  • Electrical (lighting) plan
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Ready to Get Started?

Select your plan set options before checkout.

Price Match Guarantee
What's included?

Modify this Plan

Receive a free modification quote within 3 business days.

Start with a Cost Report

Calculate the cost to build & furnish your home.

Square Footage Breakdown

Total Heated Area

2,133 sq. ft.

1st Floor

2,133 sq. ft.

Porch, Front

108 sq. ft.

Porch, Combined

341 sq. ft.

Covered Patio

233 sq. ft.

Beds/Baths

Bedrooms

3

Full bathrooms

2

Foundation Type

Standard Foundations

Crawl

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

76' 0"

Depth

40' 0"

Max Ridge Height

15' 11"

Ceiling Heights

First Floor

9'

Roof Details

Primary Pitch

1.5 on 12

Framing Type

Stick

Architectural Style

Cabin

Mid Century Modern

Modern

Mountain

Northwest

Ranch

Rustic

Special Features

Bedrooms - Split

Den

Laundry - Main Level

Master Suite - 1st Floor

Outdoor Kitchen

Two Story Great Room

Plan Collections

Canadian House Plans

Square Footage Breakdown

Total Heated Area

2,133 sq. ft.

1st Floor

2,133 sq. ft.

Porch, Front

108 sq. ft.

Porch, Combined

341 sq. ft.

Covered Patio

233 sq. ft.

Beds/Baths

Bedrooms

3

Full bathrooms

2

Foundation Type

Standard Foundations

Crawl

Exterior Walls

Exterior Walls

2x6

Dimensions

Width

76' 0"

Depth

40' 0"

Max Ridge Height

15' 11"

Ceiling Heights

First Floor

9'

Roof Details

Primary Pitch

1.5 on 12

Framing Type

Stick

Architectural Style

Cabin

Mid Century Modern

Modern

Mountain

Northwest

Ranch

Rustic

Special Features

Bedrooms - Split

Den

Laundry - Main Level

Master Suite - 1st Floor

Outdoor Kitchen

Two Story Great Room

Plan Collections

Canadian House Plans
