3-Bed Barndominium-Style House Plan with Corrugated Metal Siding and a Detached Carport

Plan 135228GRA

  • 2,679

    Heated s.f.

  • 3

    Beds

  • 2

    Baths

  • 2

    Stories

  • 2

    Cars

  • This rustic barndominium-style house plan gives you a 3-bed rustic home spec'd with corrugated metal siding and 2,679 square feet of heated living space and a detached 2-car carport.
  • French doors open from the wraparound porch taking you into an open and vaulted space giving you a combined great room, kitchen with 5' by 8' island and a coffee bar, and dining area.
  • Two spacious bedrooms line the left side, across from a full bath and laundry room with garage access.
  • The master bedroom is tucked into the rear of the design and includes a 4-fixture bathroom with a linen closet and a walk-in closet.
  • The exterior finish is spec'd for corrugated metal siding.
  • Related Plan: Get a version with an attached 3-car garage with barndominium-style house plan 135072GRA.

  • All elevations
  • Fully Dimensioned Floor Plans
  • Roof Plan & Sections
  • Foundation plan
  • General Notes
  • Suggested Electrical Layout
These items are NOT included:
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
