Plan 62603DJ

4 Bed Mediterranean with Angled Garage

Heated S.F.
2,480
Beds
4
Baths
3
Stories
2
Cars
3

Floor Plan

Plan 62603DJ

Main Level
Main Level
2nd Floor
2nd Floor

Plan 62603DJ

M-F 9am-5pm EST |

1-203-761-8500

Main Level

Plan 62603DJ: 4 Bed Mediterranean with Angled Garage - Floor Plan - Main Level - European, Northwest, Prairie

2nd Floor

Plan 62603DJ: 4 Bed Mediterranean with Angled Garage - Floor Plan - 2nd Floor - European, Northwest, Prairie

Plan Details

  • This 2-story Mediterranean-style house plan has an angled 3 car garage and an exterior with a combination of stone and stucco.
  • A covered entry greets your guests and welcomes you inside where you are swept into the open floor plan. The 2-story great room is open to the kitchen and dining area and a fireplace anchors the right wall. Windows look out across the rear deck.
  • A private den has French doors and a coffered ceiling. There is also one family bedroom on the main floor as well as the utility room with laundry off the garage entrance.
  • Upstairs, you have views to the foyer and great room below. The master occupies the left half of the home and has a tray ceiling. Two more bedrooms are across the home and share a bath.

What's Included

  • Cover Sheet: Shows the front elevation and typical notes and requirements.
  • Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurement
  • Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor
  • Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible.
  • Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
  • Roof Plan
  • Typical Wall Section
  • Typical Stair Section (if applicable)
  • Cabinets Elevations (if applicable)
View Sample Plan

What's Not Included

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Ready to Get Started?

Select your plan set options before checkout.

Price Match Guarantee
What's included?

Modify this Plan

Receive a free modification quote within 3 business days.

Start with a Cost Report

Calculate the cost to build & furnish your home.

Square Footage Breakdown

Total Heated Area

2,480 sq. ft.

1st Floor

1,472 sq. ft.

2nd Floor

1,008 sq. ft.

Beds/Baths

Bedrooms

4

Full bathrooms

3

Foundation Type

Standard Foundations

Basement

Exterior Walls

Exterior Walls

2x4

Optional Type(s)

2x6

Dimensions

Width

66' 0"

Depth

61' 0"

Max Ridge Height

30' 0"

Garage

Type

Attached

Area

731 sq. ft.

Count

3 Cars

Entry Location

Side

Ceiling Heights

Lower Level

9'

First Floor

9'

Second Floor

9'

Roof Details

Primary Pitch

6 on 12

Architectural Style

European

Northwest

Prairie

Special Features

Angled Garage

Bedrooms - Split

Den

Laundry - Main Level

Loft

Master Suite - Upstairs

Two Story Great Room

Walk-in Pantry

Square Footage Breakdown

Total Heated Area

2,480 sq. ft.

1st Floor

1,472 sq. ft.

2nd Floor

1,008 sq. ft.

Beds/Baths

Bedrooms

4

Full bathrooms

3

Foundation Type

Standard Foundations

Basement

Exterior Walls

Exterior Walls

2x4

Optional Type(s)

2x6

Dimensions

Width

66' 0"

Depth

61' 0"

Max Ridge Height

30' 0"

Garage

Type

Attached

Area

731 sq. ft.

Count

3 Cars

Entry Location

Side

Ceiling Heights

Lower Level

9'

First Floor

9'

Second Floor

9'

Roof Details

Primary Pitch

6 on 12

Architectural Style

European

Northwest

Prairie

Special Features

Angled Garage

Bedrooms - Split

Den

Laundry - Main Level

Loft

Master Suite - Upstairs

Two Story Great Room

Walk-in Pantry
