• Material Labels
• Floor-To-Floor Heights
• Roof Slope Indicators

Floor Plans - Drawn at 1/8″ to 1/4″ = 1’0″ Scale and Includes:

• Door and Window Sizes
• Completely Dimensioned Floor Plan
• Room Labels and Interior Room Sizes

Electrical Layouts:

• Building Section Markers
• All Electrical Outlets, Fixtures and Switching

Foundation or Slab Plan: - Drawn at 1/8″ to 1/4″ = 1’0″ Scale

• Floor and Deck Joist Sizes, Spacing and Direction
• Electrical Locations

Roof Design Plan - Drawn to 1/8″ to 1/4″ = 1’0″ Scale and Includes:

• All Beam and Header Heights and Locations
• All Hips, Gables, Ridges and Valley
• Building Section Markers

Building Sections - Drawn to 1/8″ to 1/4″ = 1’0″ Scale and Includes:

• Floor-To-Floor Heights
• Non-Typical Plate Heights Indicated

Typical Wall Sections - Drawn at 1/8″ to 1/2″ = 1’0″ Scale and Includes:

• All Labels Indicating Wall Construction
• Foundation Wall Thickness
• Insulation Type and Thickness

Miscellaneous Notes and Details:

• Miscellaneous General Notes
• Stairway Details (if applicable)
