Plan 83947JW
4-Bed Ranch Home Plan with Split Bedrooms
Heated S.F.
2,292
Beds
4
Baths
3
Stories
1
Cars
2
What's Included
Plan Details
  • A steeply-pitched gable rises above the double garage on the front elevation of this 4-bedroom, ranch home plan. To the left of the garage, a welcoming front porch invites you and guests inside.
  • The formal entry leads directly into the heart of the home; a combined family room, kitchen, and dining area. A fireplace anchors the left wall, while a rear porch encourages you to enjoy some fresh air, protected from the elements.
  • Flex your culinary muscles in this spacious kitchen, which features a large island, plenty of workspace, and a nearby walk-in pantry.
  • The master bedroom is located behind the 2-car garage, and joined by a 5-fixture ensuite and a roomy walk-in closet.
  • Three bedrooms can be found on the opposite side of the home; two share the hall bath, and one includes a full bath.
What's Included
  • Elevations - Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
  • Main Floor Plan - Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc
  • Second Floor Plan (if any) - Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
  • Foundation Plan - Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details. Foundation types vary; please call to confirm the foundation type of the plan you are interested in.
  • Roof Framing Plan - Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc. Specific details such as fireplaces, stairways, decks, etc. Details are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
  • Section - Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation.
  • Electrical Plan - A schematic layout of all lighting, switches and electrical outlets.
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
* Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

4-Bed Ranch Home Plan with Split Bedrooms

  • 2,292

    Heated s.f.

  • 4

    Beds

  • 3

    Baths

  • 1

    Floors

  • 2

    Car garage

Floor Plan

  • Main Level

Plan Details

Square Footage Breakdown

  • Total: 2,292 sq. ft.
  • 1st Floor: 2,292 sq. ft.

Dimensions

  • Width: 77' 0"
  • Depth: 56' 0"
  • Max ridge height: 30' 5"

Beds/Baths

  • Bedrooms: 4
  • Full bathrooms: 3

Garage

  • Type: Attached
  • Area: 654 sq. ft.
  • Count: 2 Cars
  • Entry Location: Front

Foundation Type

    • Standard Foundations: Monolithic Slab, Slab

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 9' 0"

Roof

  • Primary Pitch: 12 on 12
  • Framing Type: Stick
