Plan 580028DFT
4100 Sq Ft Single-Story Country Ranch House Plan with 4 Bedrooms
Heated S.F.
4,092
Beds
4
Baths
4
Stories
1
Cars
3
What's Included
Plan Details
  • This 4,092 sq ft Country Ranch house plan gives you 4 beds, 4 baths, and offers a feature-rich layout including a home office, exercise room, butlery with wet bar, and a large flex room that would make a perfect home theater room.
  • The open living space creates a family-friendly environment to host dinners and holidays. A kitchen island anchors the space and the adjacent butlery includes a wet bar and access to the pantry.
  • The homeowner's oasis boasts a spa-like ensuite with an exercise room and walk-in closet that connects to the laundry room.
  • Three additional bedroom suites and a home office are sprinkled throughout the design.
  • Discover extra room in the 3-car garage for storage or lawn supplies and a mudroom just inside serves as the drop zone when coming or going.
What's Included

  • Cover Sheet: General Notes and code criteria
  • Foundation Plan: Concrete layouts including footings, slabs and stem walls, dimensions, floor joist layout, plumbing fixture locations and construction notes and details
  • Floor Plan(s): Dimensions, wall framing, room sizes, door and window location and sizes, plumbing fixtures, kitchen layout with cabinetry location and construction notes and details
  • Roof Plan: Bird's eye view and general layout, roof pitches, eave sizes, special ceiling heights, trey ceilings located and construction notes and details
  • Section View(s): A cut or cuts through the home showing wall plate heights, stair sections, special construction sections including footings and crawl space or slab details
  • Exterior Elevations: Shows 2-D exterior views of all 4 sides of home locating and showing roof lines, roof pitches, material callouts, window locations, vents, trim style and plate heights
  • Electrical Plans: General layout of smoke detectors, carbon monoxide detectors, exhaust fans, lights, switches, outlets and GFI outlets

What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
