Plan 135175GRA Barndominium-style House Plan with Massive Locker Room

Barndominium-style House Plan with Massive Locker Room

Plan 135175GRA

  • 1,986

    Heated s.f.

  • 3

    Beds

  • 2.5+

    Baths

  • 2

    Stories

  • 2

    Cars

  • Board and batten siding mimics the ribbed metal roof on the exterior of this New Ameridcan Barndominium-style house plan (stick-framing).
  • The right side of this design is where you'll find the 1,182 square foot garage - open to above - complete with a powder bath and large locker room with indoor and outdoor access
  • A wraparound porch surrounds the living room, which opens to the eat-in kitchen; a dream layout for entertaining.
  • The master bedroom is located on the main level and features a tile shower in the attached bathroom, along with a shortcut to the laundry room.
  • Upstairs, discover a sizable loft, as well as bedrooms 2 and 3 that share a full bath and a balcony overlooking the living room, dining room and kitchen. Through the door, you reach the loft which looks down on the garage along with a second set of stairs.
  • Related Plans: Get an alternate version with house plans 135160GRA135179GRA and 135075GRA.

  • All elevations
  • Fully Dimensioned Floor Plans
  • Roof Plan & Sections
  • Foundation plan
  • General Notes
  • Suggested Electrical Layout
These items are NOT included:
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

Floor Plan

NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Barndominium-style House Plan with Massive Locker Room - 135175GRA floor plan - Main Level
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Barndominium-style House Plan with Massive Locker Room - 135175GRA floor plan - 2nd Floor

Plan details

Barndominium-style House Plan with Massive Locker Room

  • 1,986

    Heated s.f.

  • 3

    Beds

  • 2.5+

    Baths

  • 2

    Floors

  • 2

    Car garage

Buy This Plan
  • PDF - Single-Build $1,050
  • 5 Sets $1,200
  • 5 Sets + PDF $1,300
  • PDF - Unlimited Build $1,550
  • CAD + PDF - Single-Build $2,100
  • CAD - Unlimited Build $2,600
  • View all purchase option online

About This Plan

  • Board and batten siding mimics the ribbed metal roof on the exterior of this New Ameridcan Barndominium-style house plan (stick-framing).
  • The right side of this design is where you'll find the 1,182 square foot garage - open to above - complete with a powder bath and large locker room with indoor and outdoor access
  • A wraparound porch surrounds the living room, which opens to the eat-in kitchen; a dream layout for entertaining.
  • The master bedroom is located on the main level and features a tile shower in the attached bathroom, along with a shortcut to the laundry room.
  • Upstairs, discover a sizable loft, as well as bedrooms 2 and 3 that share a full bath and a balcony overlooking the living room, dining room and kitchen. Through the door, you reach the loft which looks down on the garage along with a second set of stairs.
  • Related Plans: Get an alternate version with house plans 135160GRA135179GRA and 135075GRA.

Floor Plans

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total Heated Area: 1,986 sq. ft.
  • 1st Floor: 1,320 sq. ft.
  • 2nd Floor: 666 sq. ft.

Beds/Baths

  • Bedrooms: 3
  • Full bathrooms: 2
  • Half bathrooms: 2

Foundation Type

    • Standard Foundations: Slab

Exterior Walls

  • Standard Type(s): 2x6

Dimensions

  • Width: 70' 0"
  • Depth: 40' 0"
  • Max ridge height: 27' 5"

Garage

  • Type: RV Garage, Attached
  • Area: 1182 sq. ft.
  • Count: 2 Cars
  • Entry Location: Side, Front

Ceiling Heights

  • Floor / Height: First Floor / 10' 0" Second Floor / 9' 0"

Roof

  • Framing Type: Truss
