Charming Dormers

Plan 59633ND

  • 3,005

    Heated s.f.

  • 3-4

    Beds

  • 3.5

    Baths

  • 2

    Stories

  • 2

    Cars

  • Charming dormers and a covered porch add curb appeal to this home plan. From the foyer you'll notice and appreciate the openness of this design. The expansive great room with fireplace merges seamlessly into the dining room and kitchen to create the perfect area for entertaining. A large rear screened porch and grilling patio also lend outdoor possibilities.
  • Two secondary bedrooms and the luxurious master suite complete the main level.
  • The upper floor houses a huge loft area with computer center and another bedroom and full bath.
  • Related Plans: Get a one-story version with house plan 5980ND and get a detached garage with house plan 5923ND.

Each plan set includes the following:

  • Foundation Plan** (1/4″ or 1/2″ = 1′)
  • Floor Plans (1/4″= 1′)
  • Set of Elevations (1/4″= 1′)
  • Miscellaneous Details (3/4″ = 1′)
  • An electrical diagram showing a birdseye view of rooms with lights, fans to switches
These items are NOT included:

  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required

NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Charming Dormers - 59633ND floor plan - Main Level
NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Charming Dormers - 59633ND floor plan - 2nd Floor

Charming Dormers

  • 3,005

    Heated s.f.

  • 3-4

    Beds

  • 3.5

    Baths

  • 2

    Floors

  • 2

    Car garage

Floor Plan

  • Main Level

  • 2nd Floor

Plan Details

Square Footage Breakdown

  • Total: 3,005 sq. ft.
  • 1st Floor: 2,277 sq. ft.
  • 2nd Floor: 728 sq. ft.

Dimensions

  • Width: 67' 8"
  • Depth: 72' 6"
  • Max ridge height: 27' 2"

Beds/Baths

  • Bedrooms: 3 or 4
  • Full bathrooms: 3
  • Half bathrooms: 1

Garage

  • Type: Attached
  • Area: 649 sq. ft.
  • Count: 2 Cars
  • Entry Location: Side

Foundation Type

    • Standard Foundations: Slab, Crawl
    • Optional Foundations: Basement, Walkout

Exterior Walls

  • Standard Type(s): 2x4
  • Optional Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 9' 0" Second Floor / 8' 0"

Roof

  • Primary Pitch: 12 on 12
  • Secondary Pitch: 5 on 12
  • Framing Type: Stick
