Coastal Contemporary House Plan with Upstairs Rec Room and Balcony - 4621 Sq Ft

Name: Plan 86141BW: Coastal Contemporary House Plan with Upstairs Rec Room and Balcony - 4621 Sq Ft
Brand: Architectural Designs
SKU: 86141BW
Price: 3369.60 USD
Availability: InStock

Heated S.F.

4,621

Beds

Baths

5.5+

Stories

Cars

Floor Plan

Main Level

2nd Floor

Plan Details

This coastal contemporary house plan gives you one-level living with a second floor rec room with a covered balcony. Overall, the home plan gives you 5 beds and 4,621 square feet of heated living.
Enjoy outdoor living on the covered lanai in back, complete with fireplace and outdoor kitchen - and spread out across the 990 square feet of covered space.
A 2-car garage on the left and a 1-car garage on the right - both of them courtyard entry - combine to deliver 1,004 square feet of parking.
Architectural Designs' primary focus is to make the process of finding and buying house plans more convenient for those interested in constructing new homes - single family and multi-family ones - as well as garages, pool houses and even sheds and backyard offices.
Our website offers a vast collection of home designs, encompassing various architectural styles, sizes, and features, which can be customized to meet specific needs and preferences.
We curate and add to our design portfolio every day as we work with hundreds of residential building designers and architects to bring you the most diverse and best house plans available.
We can modify any house plan you see on our site. Learn more about modifications.
