Plan 65766BS

Coastal Contemporary Three Bedroom House Plan with Open Concept Layout

Name: Plan 65766BS: Coastal Contemporary Three Bedroom House Plan with Open Concept Layout
Brand: Architectural Designs
SKU: 65766BS
Price: 1847.0 USD
Availability: InStock

Heated S.F.

1,847

Beds

Baths

Stories

Cars

Floor Plan

Plan Details

This 1,847 square foot Florida-style ranch offers a seamless blend of modern design and functional living with three bedrooms and two full bathrooms.
The exterior showcases a sleek, low-profile contemporary aesthetic that is perfectly suited for warm climates and relaxed coastal living.
Upon entry, the home reveals an airy, open-concept floor plan that draws natural light deep into the heart of the residence.
The main living area serves as a central hub, effortlessly connecting the kitchen and dining spaces for comfortable daily interaction.
A dedicated master suite provides a peaceful, private retreat, while two secondary bedrooms are thoughtfully clustered to ensure convenience for family or guests.
The inclusion of a bright dining area and a dedicated main-level laundry room adds practical luxury to this efficient and well-designed home.

What's Included

Elevations: - Drawn at 1/8″ to 1/4″ = 1’0″ Scale and Includes:

Material Labels
Floor-To-Floor Heights
Roof Slope Indicators

Floor Plans: - Drawn at 1/8″ to 1/4″ = 1’0″ Scale and Includes:

Door and Window Sizes
Completely Dimensioned Floor Plan
Room Labels and Interior Room Sizes

Electrical Layouts:

Building Section Markers
All Electrical Outlets, Fixtures and Switching

Foundation or Slab Plan: - Drawn at 1/8″ to 1/4″ = 1’0″ Scale and Includes:

Floor and Deck Joist Sizes, Spacing and Direction
Electrical Locations

Roof Design Plan: - Drawn to 1/8″ to 1/4″ = 1’0″ Scale and Includes:

All Beam and Header Heights and Locations
All Hips, Gables, Ridges and Valley
Building Section Markers

Building Sections: - Drawn to 1/8″ to 1/4″ = 1’0″ Scale and Includes:

Floor-To-Floor Heights
Non-Typical Plate Heights Indicated

Typical Wall Sections: - Drawn at 1/8″ to 1/2″ = 1’0″ Scale and Includes:

All Labels Indicating Wall Construction
Foundation Wall Thickness
Insulation Type and Thickness

Miscellaneous Notes and Details:

Miscellaneous General Notes
Stairway Details (if applicable)

What's Not Included

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required

IMPORTANT NOTE: Structural drawings, as well as heating and plumbing details, will not be included in your plan sets due to a variety of factors which include local codes, installation methods, personal preference, etc. Your building professional (contractor/builder/supplier) can, without difficulty, supply these details and specifications on your behalf.
