Coastal Florida Style House Plan with 3 Bedrooms and Courtyard Entry

Name: Plan 65828BS: Coastal Florida Style House Plan with 3 Bedrooms and Courtyard Entry
Brand: Architectural Designs
SKU: 65828BS
Price: 2024.44 USD
Availability: InStock

Heated S.F.

2,802

Beds

Baths

2.5

Stories

Cars

Floor Plan

Plan Details

This sophisticated 2,802 square foot residence blends coastal and contemporary design, featuring 3 bedrooms, 2.5 baths, and a spacious 1,031 square foot 3-car garage.
A private courtyard entry welcomes you into a thoughtfully laid-out floor plan that prioritizes natural light and seamless transitions.
The expansive main living area flows effortlessly, anchored by a gourmet kitchen equipped with a large walk-in pantry that serves as the heart of the home.
The primary bedroom suite offers a serene retreat, positioned in a split-bedroom layout that ensures maximum privacy from the two secondary bedrooms.
An impressive 829 square foot lanai featuring an outdoor kitchen extends the living space, creating an ideal environment for enjoying warm breezes and alfresco dining.
The home includes a dedicated library for quiet work and a convenient mudroom, with an additional 921 square foot bonus room available to be finished for extra living or media space.

What's Included

Elevations: - Drawn at 1/8″ to 1/4″ = 1’0″ Scale and Includes:

Material Labels
Floor-To-Floor Heights
Roof Slope Indicators

Floor Plans: - Drawn at 1/8″ to 1/4″ = 1’0″ Scale and Includes:

Door and Window Sizes
Completely Dimensioned Floor Plan
Room Labels and Interior Room Sizes

Electrical Layouts:

Building Section Markers
All Electrical Outlets, Fixtures and Switching

Foundation or Slab Plan: - Drawn at 1/8″ to 1/4″ = 1’0″ Scale and Includes:

Floor and Deck Joist Sizes, Spacing and Direction
Electrical Locations

Roof Design Plan: - Drawn to 1/8″ to 1/4″ = 1’0″ Scale and Includes:

All Beam and Header Heights and Locations
All Hips, Gables, Ridges and Valley
Building Section Markers

Building Sections: - Drawn to 1/8″ to 1/4″ = 1’0″ Scale and Includes:

Floor-To-Floor Heights
Non-Typical Plate Heights Indicated

Typical Wall Sections: - Drawn at 1/8″ to 1/2″ = 1’0″ Scale and Includes:

All Labels Indicating Wall Construction
Foundation Wall Thickness
Insulation Type and Thickness

Miscellaneous Notes and Details:

Miscellaneous General Notes
Stairway Details (if applicable)

What's Not Included

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required

IMPORTANT NOTE: Structural drawings, as well as heating and plumbing details, will not be included in your plan sets due to a variety of factors which include local codes, installation methods, personal preference, etc. Your building professional (contractor/builder/supplier) can, without difficulty, supply these details and specifications on your behalf.
