Contemporary Lakehouse Plan with Spacious Front Deck and 4-Sided Fireplace

Plan 680196VR

  • 1,883

    Heated s.f.

  • 2

    Beds

  • 2.5

    Baths

  • 1

    Stories

  • 2

    Cars

  • This contemporary lake house plan gives you 1,883 square feet of heated living with 2 beds, 2 baths and a 763 square foot 3-car garage with one side loading bay and two front loading ones.
  • Windows fill the front wall and angled timbers support the deep-eave roof giving the home amazing curb appeal. A 48' by 16' deck - accessible from the living room - gives you 768 square feet of fresh air to enjoy.
  • The kitchen, living room and dining room are under a ceiling that slopes from 16' to 10'. A 4-sided fireplace cleverly divides the space which is free of interior walls.
  • The master suite has views to the front, two vanities, a walk-in shower, a sauna in the private bath along with a walk-in closet. The second bedroom is accessible either from the living room or the kitchen.
  • Related Plan: Get a slightly smaller version with house plan 680192VR (1,796 sq. ft.).

This plan set has the following details:

a) Floor Plans: House plan drawings indicating dimensions for construction

b) Roof Plan: Drawings indicating roof slopes and unique conditions

c) Exterior Elevations: Drawings showing appearance and the types of materials used for the exterior finish and trim

d) Building Sections: Drawings cut through important locations in the structure

e) Construction Details: Drawings showing specific construction of building elements at a large scale

f) Kitchen and bath elevations (excluded on garage plans)

g) Electrical Plans: Basic electrical layout (suggested locations of fixtures, switches and outlets)

h) Foundation Plan: Dimensioned drawings describing specific foundation conditions for the structure

i) A building license: A single-use license for construction at one location only


These items are NOT included:


  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required


NOTE:
If you want to purchase this plan in reverse, please select "readable reverse" or "mirror reverse" under Options above.
Contemporary Lakehouse Plan with Spacious Front Deck and 4-Sided Fireplace - 680196VR floor plan - Main Level

Contemporary Lakehouse Plan with Spacious Front Deck and 4-Sided Fireplace

  • 1,883

    Heated s.f.

  • 2

    Beds

  • 2.5

    Baths

  • 1

    Floors

  • 2

    Car garage

Floor Plan

  • Main Level

Plan Details

Square Footage Breakdown

  • Total: 1,883 sq. ft.
  • 1st Floor: 1,883 sq. ft.
  • Rear Patio: 200 sq. ft.

Dimensions

  • Width: 80' 5"
  • Depth: 60' 0"
  • Max ridge height: 18' 6"

Beds/Baths

  • Bedrooms: 2
  • Full bathrooms: 2
  • Half bathrooms: 1

Garage

  • Type: Attached
  • Area: 763 sq. ft.
  • Count: 2 Cars
  • Entry Location: Side, Front

Foundation Type

    • Standard Foundations: Slab, Crawl
    • Optional Foundations: Basement, Walkout

Exterior Walls

  • Standard Type(s): 2x6

Roof

  • Primary Pitch: 2 on 12
  • Framing Type: Stick
