Contemporary Northwest Home with Open Main Level
Heated S.F.
2,702
Beds
3-4
Baths
2.5
Stories
2
Cars
2
What's Included
Plan Details
  • Clean, straight lines define the exterior of this contemporary Northwest home, while oversized windows allow natural light to infiltrate the interior.
  • The two-story foyer provides a grand first impression, and a nearby coat closet and powder bath serve both the formal and garage entries.
  • Towards the back of the main level, discover an eat-in kitchen, which opens to a great room. A covered deck invites you to enjoy the breeze with friends and family.
  • Upstairs, you'll find the master suite, with a barn door granting access to the 5-fixture bath. Two additional bedrooms across the hall share a full bath.
  • The laundry room is centrally located for easy access, and a fourth room on the second level could serve as a bedroom or common space, if preferred.
What's Included
Included:
• Cover Sheet with plan info
• General notes - Note: codes will not include local state adopted amendments
• Fully dimensions and detailed floor plans
• Elevations
• Building cross section
• Roof Plan
• Details
• Window Schedule
• Original Structural plan FOR REFERENCE ONLY

These items are NOT included:

• Architectural or Engineering Stamp  - handled locally when required
• Site plans - handled locally - handled locally when required
• Mechanical Drawings - handled locally when required
• Plumbing Drawings  - handled locally when required
• Electrical Drawings  - handled locally when required
• Energy Calculations  - handled locally when required
• Foundation and Framing plans   - handled locally when required
