Plan 135149GRA
Contemporary Ranch Home Plan with Angled Garage
Heated S.F.
3,136
Beds
2
Baths
2.5
Stories
1
Cars
2
What's Included
Plan Details
  • This Contemporary Ranch home plan features mid-century modern influences, over 3,100 sq ft of living space, and an angled garage with attached storage bay.
  • Large windows overlook the back patio from the great room and oversized openings create a free-flowing design into the kitchen and dining room.
  • The gourmet kitchen includes a cooktop island, large walk-in pantry, and adjacent covered patio for outdoor dining no matter the weather.
  • Walk past the study to find two bedrooms, both with vaulted ceilings. The master enjoys rearward views and a 5-fixture bathroom with a walk-in closet.
  • The laundry room, half bath, and 2-car garage protrude at an angle, and the homeowner will appreciate the dedicated storage bay with an overhead door, perfect for lawn equipment or supplies.
What's Included
  • Elevations
  • Fully Dimensioned Floor Plans
  • Roof Plan & Sections
  • Foundation plan
  • General Notes
  • Suggested Electrical Layout
Sample Plan
What's Not Included
  • Architectural or Engineering Stamp - handled locally if required
  • Site Plan - handled locally when required
  • Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
  • Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
  • Energy calculations - handled locally when required
Print
Hide
Compare
Favorite
* Please note that all sale prices and promotions featured on our website are subject to change without prior notice. While we strive to provide accurate and up-to-date information, occasional discrepancies may occur due to factors beyond our control. We encourage you to verify all details, including pricing and availability, before making any purchase. Exclusions or restrictions may apply to specific promotions. We reserve the right to modify or cancel any sale at our discretion. Thank you for your understanding and happy shopping! Let's go back to the top.

Contemporary Ranch Home Plan with Angled Garage

  • 3,136

    Heated s.f.

  • 2

    Beds

  • 2.5

    Baths

  • 1

    Floors

  • 2

    Car garage

Floor Plan

  • Main Level

Plan Details

Square Footage Breakdown

  • Total: 3,136 sq. ft.
  • 1st Floor: 3,136 sq. ft.

Dimensions

  • Width: 78' 0"
  • Depth: 64' 6"
  • Max ridge height: 18' 0"

Beds/Baths

  • Bedrooms: 2
  • Full bathrooms: 2
  • Half bathrooms: 1

Garage

  • Type: Attached
  • Area: 840 sq. ft.
  • Count: 2 Cars

Foundation Type

    • Standard Foundations: Slab
    • Optional Foundations: Walkout, Crawl

Exterior Walls

  • Standard Type(s): 2x6

Ceiling Heights

  • Floor / Height: First Floor / 10' 0"
