Plan 470318REY

Country House Plan with 3 Beds, Office, and 3-Car Garage

Name: Plan 470318REY: Country House Plan with 3 Beds, Office, and 3-Car Garage
Brand: Architectural Designs
SKU: 470318REY
Price: 1395.0 USD
Availability: InStock

Heated S.F.

2,088

Beds

Baths

Stories

Cars

Floor Plan

Main Level

Plan Details

This 2,088 sq ft Ranch-style Country house plan offers 3 bedrooms, 2 bathrooms, and a spacious 936 sq ft, 3-car side-entry garage, all wrapped in a modern country aesthetic.
A welcoming 464 sq ft front porch leads into an open-concept layout, featuring a dedicated home office and a convenient mudroom upon entry.
The heart of the home is the great room, boasting a 14' 10'' cathedral ceiling, seamlessly connected to a breakfast nook and a butler walk-in pantry for effortless living and entertaining.
The main level features a private primary bedroom suite, thoughtfully separated from the 2 or 3 secondary bedrooms for ultimate tranquility and comfort.
A dedicated workshop space provides an ideal area for hobbies or projects.
Enjoy expansive outdoor living with both a generous 464 sq ft front porch and a sprawling 544 sq ft rear porch, perfect for enjoying the views and the fresh air.
Related Plan: Get a smaller version with a front-entry 2-car garage with drive-thru bay with house plan 470321REY (1,664 sq. ft.)

What's Included

Cover Sheet: Includes front elevation or perspective, plan description, general notes, building footprint, building area breakdowns, drawing sheet index, etc. These elements are not to scale.
Floor Plan: Includes layout of each floor with locations and dimensions of walls, doors, and windows. Overhead beams and vaults are indicated. Shows locations of cabinetry, appliances, plumbing fixtures, closets and shelf packs.
Exterior Elevations: Shows front, sides and back building elevations along with roof pitches, and exterior siding and trim materials.
Typical Section: Usually drawn to ½”=1’-0”. Shows a cross-section of the building with typical elements such as ceiling and header heights, roof style, insulation locations (thermal envelope), and foundation style. Specific details may be shown in an additional Typical Wall Section, if included.
Electrical Plan: Includes a general suggested layout of light fixtures, switches, and electrical outlets.
Foundation Plan: Shows locations of foundation walls, strip footings and pier pads.
Floor Framing Plan: First floor framing may be combined with Foundation Plan. Shows floor framing type, spacing and direction along with supporting element locations.
Roof Framing Plan: Shows truss/rafter spacing and direction, typical overhangs, roof outline, supporting member locations, and over framing locations (if any).
Typical Details: Scales may vary, typically at to ½”=1’-0” or to 1”=1’-0”, some not to scale. Shows the suggested typical details such as transitions from foundation to walls, walls to ceiling/roof, general flashing strategies, and other connection points. Other specific architectural finish details may be included at designer’s discretion.
Interior Elevations of Cabinetry may be included, but are not always part of a standard drawing set.

This is a general description of the content of each main drawing set element. Elements may be grouped on single sheets for smaller plans or over multiple sheets for larger plans. Additional information may be included. All information provided, and particularly any structural information, simply reflects the conditions of the original build location and may not be appropriate for the plan purchaser’s build location and are included for reference only. Therefore, all drawing information is to be verified by a person qualified to ensure compliance with the actual build location conditions and regulations as needed. Unless otherwise noted, elements are typically drawn to a scale of ¼”=1’-0”.

What's Not Included

Architectural or Engineering Stamp - handled locally if required
Site Plan - handled locally when required
Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
Plumbing Drawings (drawings showing the actual plumbing pipe sizes and locations) - your subcontractors handle this
Energy calculations - handled locally when required
